AP7502 Dual Radio Wallplate AP Test Setup Photos - FCC ID UZ7AP7502

FCC ID UZ7AP7502

Test Setup Photos

Dual Radio Wallplate AP

by Zebra Technologies Corporation

Document preview loads when visible.

Document Details

FCC IDUZ7AP7502
Document ID2656805
Document TypeTest Setup Photos
DescriptionTest Setup Photos
Document Titleuntitled
ApplicantZebra Technologies Corporation
Equipment ClassDual Radio Wallplate AP
Product CodeAP7502
Application IDyNh0yglbJndvYtssM5REEg==
Application PurposeClass II Permissive Change
Application Date2015-09-14
Frequency Range5180-5240 MHz
FRN0015642663
Test FirmBureau Veritas CPS (H.K.) Ltd., Taoyuan Branch
Certified ByAmanda Wu
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2015-06-24
Available2015-09-14
Created2014-11-11
Modified2014-11-11
Pages4
File TypeAdobe Acrobat PDF
File Size558044
File SHA-2566fc4099ebc615be80d3cc50af23548f1afae8c6713719e75798eafef0ff2e511
PDF Metadata ProducerAcrobat Distiller 11.0 (Windows)
FCC.gov SourcesFCC.gov 2656805
