FCC ID UZ7MPACTHUBFXD
Hub
by Zebra Technologies Corporation
Grantee Code: UZ7 Product Code: MPACTHUBFXD
Latest application date: 2016-12-22
Device Images
FCC ID Device Details
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2402-2480 MHz | Original Equipment | 2016-12-22 |
| 5180-5240 MHz | Original Equipment | 2016-12-22 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Installation Guide | Users Manual | 2017-06-20 | PDF 2.3 MB |
| Installation Guide User Guide | Users Manual | 2017-06-20 | PDF 2.3 MB |
| User Manual | Users Manual | 2017-06-20 | PDF 210 KB |
| Internal Photo | Internal Photos | 2017-06-20 | PDF 1.7 MB |
| External Photo | External Photos | 2017-06-20 | PDF 813 KB |
| Declaration of Label Location | Cover Letter(s) | 2016-12-22 | PDF 84.5 KB |
| Label Location | ID Label/Location Info | 2016-12-22 | PDF 166.9 KB |
| Label Sample | ID Label/Location Info | 2016-12-22 | PDF 394.4 KB |
| Test Setup Photo DTS BT LE | Test Setup Photos | 2017-06-20 | PDF 448.9 KB |
| Test Setup Photos DTS WLAN | Test Setup Photos | 2017-06-20 | PDF 455.4 KB |
| Test Setup Photos NII DFS | Test Setup Photos | 2017-06-20 | PDF 147.5 KB |
| Test Setup Photos NII WLAN B1-B3 | Test Setup Photos | 2017-06-20 | PDF 455.3 KB |
| Test Setup Photos NII WLAN B4 | Test Setup Photos | 2017-06-20 | PDF 455.2 KB |
| Test Report DTS BT LE | Test Report | 2016-12-22 | PDF 1.9 MB |
| Test Report DTS WLAN | Test Report | 2016-12-22 | PDF 2.9 MB |
| Test Report NII DFS | Test Report | 2016-12-22 | PDF 763 KB |
| Test Report NII WLAN B1-B3 | Test Report | 2016-12-22 | PDF 3.6 MB |
| Test Report NII WLAN B4 | Test Report | 2016-12-22 | PDF 1.9 MB |
| Cover Letter | Cover Letter(s) | 2016-12-22 | PDF 114 KB |
| RF Exposure | RF Exposure Info | 2016-12-22 | PDF 416.5 KB |
| Block Diagram Metadata only | Block Diagram | PDF 119.9 KB | |
| Schematics Metadata only | Schematics | PDF 250.2 KB | |
| Operational Description Metadata only | Operational Description | PDF 542 KB | |
| Operational Description EE FctSpec Metadata only | Operational Description | PDF 684.1 KB | |
| Operational Description Software Security Metadata only | SDR Software/Security Inf | PDF 462.4 KB | |
| BOM Metadata only | Parts List/Tune Up Info | PDF 50.5 KB | |
| Tune Up Pro Metadata only | Parts List/Tune Up Info | PDF 36.4 KB |
Application Information
| Application ID | hG1Etf2VY7BPCSgDnSsYYA== |
|---|---|
| Final Action Date | 2016-12-22 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0015642663 |
| Model | MPACTHUBFXD |
| Frequency Range | 2402-2480 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | Hub |
| Responsible Party | Qianlin Zhou, Regulatory Specialist, Larry.Zhou@zebra.com  , 346-260-3543 |
| Test Firm | Alex Chen, SPORTON International Inc., alex@sporton.com.tw  , 886-3-327-3456 |
| TCB Email | TEI@TIMCOENGR.COM  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | Yes |
| Short-Term Confidentiality Date | 06/20/2017 |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power listed is maximum combined output power conducted. This device is restricted to indoor use only. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not transmit simultaneously with any other antenna or transmitter, except in accordance with FCC multitransmitter product procedures. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
