TW5 2x2 802.11n PCIe MODULE Teardown Internal Photos - FCC ID UZ7TW5

FCC ID UZ7TW5

Internal Photos

2x2 802.11n PCIe MODULE

by Zebra Technologies Corporation

Document preview loads when visible.

Document Details

FCC IDUZ7TW5
Document ID2009331
Document TypeInternal Photos
DescriptionInternal Photos
Document TitleTW-5_Single_File_Photographs_Internal
ApplicantZebra Technologies Corporation
Equipment Class2x2 802.11n PCIe MODULE
Product CodeTW5
Application IDbrB/ANP7asM/6v/bJtyS2A==
Application PurposeOriginal Equipment
Application Date2013-07-05
Frequency Range5180-5240 MHz
FRN0007722119
Test FirmSporton International Inc.
Certified ByLEO HUANG MANAGER
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2013-07-05
Available2013-07-05
Created2013-06-24
Modified2013-06-24
Pages2
File TypeAdobe Acrobat PDF
File Size248834
File SHA-256ebf0a935de868d9cedef3eb6080c102ceca2453c22adb86074bc1da4dba66ccd
PDF Metadata AuthorSandy
PDF Metadata CreatorPScript5.dll Version 5.2.2
PDF Metadata ProducerAcrobat Distiller 9.0.0 (Windows)
FCC.gov SourcesFCC.gov 2009331, FCC.gov 2009317
