FCC ID V2V-2901
Broadband Digital Transmission System
by LigoWave LLC
Grantee Code: V2V Product Code: 2901
Latest application date: 2016-09-19
Device Images
FCC ID Device Details
| FCC ID | V2V-2901 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | V2V |
| Product Code | 2901 |
| Applicant Business | LigoWave LLC 🇺🇸 |
| Related Domains |  function-g.com |
| Equipment Class | Broadband Digital Transmission System |
| Test Firm | Shenzhen Alpha Product Testing Co., Ltd. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 5180-5240 MHz | Original Equipment | 2016-09-19 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User manual | Users Manual | 2016-09-19 | PDF 933.1 KB |
| Internal photos | Internal Photos | 2016-09-19 | PDF 1.1 MB |
| External photos | External Photos | 2016-09-19 | PDF 3.3 MB |
| Label | ID Label/Location Info | 2016-09-19 | PDF 1.8 MB |
| Test setup | Test Setup Photos | 2016-09-19 | PDF 388.9 KB |
| Test report part 1 | Test Report | 2016-09-19 | PDF 3.5 MB |
| Test report part 2 | Test Report | 2016-09-19 | PDF 1.7 MB |
| Cover letter | Cover Letter(s) | 2016-09-19 | PDF 170.4 KB |
| RF Exposure | RF Exposure Info | 2016-09-19 | PDF 71.7 KB |
| Block Diagram Metadata only | Block Diagram | PDF 14.9 KB | |
| Schematics Metadata only | Schematics | PDF 414.5 KB | |
| Operational Description Metadata only | Operational Description | PDF 187.7 KB | |
| Software Security Metadata only | SDR Software/Security Inf | PDF 309.3 KB |
Application Information
| Application ID | Ev5UebyagPg7Ktxzyryxeg== |
|---|---|
| Final Action Date | 2016-09-19 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0017416041 |
| Model | 2901 |
| Frequency Range | 5180-5240 MHz |
| Equipment Class | NII - Unlicensed National Information Infrastructure TX |
| Device Description | Broadband Digital Transmission System |
| Responsible Party | Simon Chou, General Manager, simonchou@function-g.com , 8775446928 |
| Test Firm | Mark Zhu, Shenzhen Alpha Product Testing Co., Ltd., mark@a-lab.cn  , 86-755-86375552 |
| TCB Email | stuart.beck@nemko.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Single Modular Approval. Power output listed is conducted. This device has a 20 MHz, 40 MHz and 80 MHz bandwidth mode. Approval is limited to OEM installation only. Compliance of this device in all final host configurations is the responsibility of the Grantee. This device is to be used only for professional installed fixed point-to-point applications. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 280 cm from all persons and must not be co-located or operating in conjunction with any other transmitter. OEM integrators must be provided with antenna installation instructions and labeling requirements for finished products. OEM integrators and End-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| Ev5UebyagPg7Ktxzyryxeg== | 2016-09-19 | Original Equipment |
Equipment Authorization
Grants
TCB Grant - Application Ev5UebyagPg7Ktxzyryxeg==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Nemko North America, INC. 303 River Road Ottawa, Ontario, K1V 1H2 Canada |
Date of Grant: 09/19/2016 Application Dated: 09/19/2016 |
| LigoWave LLC |
| 138 Mountain Brook Dr |
| Canton, GA 30115 |
| Attention: Simon Chou , General Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | V2V-2901 |
| Name of Grantee: | LigoWave LLC |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Broadband Digital Transmission System |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 MO | 15E | 5180.0 - 5240.0 | 0.094 | ||
| 38 MO | 15E | 5745.0 - 5825.0 | 0.853 |
| Single Modular Approval. Power output listed is conducted. This device has a 20 MHz, 40 MHz and 80 MHz bandwidth mode. Approval is limited to OEM installation only. Compliance of this device in all final host configurations is the responsibility of the Grantee. This device is to be used only for professional installed fixed point-to-point applications. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 280 cm from all persons and must not be co-located or operating in conjunction with any other transmitter. OEM integrators must be provided with antenna installation instructions and labeling requirements for finished products. OEM integrators and End-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application Ev5UebyagPg7Ktxzyryxeg==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
LigoWave LLC 138 Mountain Brook Dr Canton, GA 30115 United States |
Date of Grant: 09/19/2016 Application Dated: 09/19/2016 |
| Attention: Simon Chou , General Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | V2V-2901 |
| Name of Grantee: | LigoWave LLC |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Broadband Digital Transmission System |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 MO | 15E | 5180.0 - 5240.0 | 0.094 | ||
| 38 MO | 15E | 5745.0 - 5825.0 | 0.853 |
| Single Modular Approval. Power output listed is conducted. This device has a 20 MHz, 40 MHz and 80 MHz bandwidth mode. Approval is limited to OEM installation only. Compliance of this device in all final host configurations is the responsibility of the Grantee. This device is to be used only for professional installed fixed point-to-point applications. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 280 cm from all persons and must not be co-located or operating in conjunction with any other transmitter. OEM integrators must be provided with antenna installation instructions and labeling requirements for finished products. OEM integrators and End-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
