FCC ID V2V-3000
Broadband Digital Transmission System
by LigoWave LLC
Grantee Code: V2V Product Code: 3000
Latest application date: 2016-08-07
Device Images
FCC ID Device Details
| FCC ID | V2V-3000 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | V2V |
| Product Code | 3000 |
| Applicant Business | LigoWave LLC 🇺🇸 |
| Related Domains |  function-g.com |
| Equipment Class | Broadband Digital Transmission System |
| Test Firm | Shenzhen Alpha Product Testing Co., Ltd. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2412-2462 MHz | Original Equipment | 2016-08-07 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User manual | Users Manual | 2016-08-07 | PDF 497.4 KB |
| Internal photos | Internal Photos | 2016-08-07 | PDF 376.9 KB |
| External photos | External Photos | 2016-08-07 | PDF 681 KB |
| Label | ID Label/Location Info | 2016-08-07 | PDF 197.8 KB |
| Test setup | Test Setup Photos | 2016-08-07 | PDF 293.9 KB |
| Test report part 1 | Test Report | 2016-08-07 | PDF 4.7 MB |
| Test report part 2 | Test Report | 2016-08-07 | PDF 4 MB |
| Test report part 3 | Test Report | 2016-08-07 | PDF 678.7 KB |
| Cover letter | Cover Letter(s) | 2016-08-07 | PDF 168 KB |
| RF Exposure | RF Exposure Info | 2016-08-07 | PDF 71.6 KB |
| Block Diagram Metadata only | Block Diagram | PDF 13.7 KB | |
| Schematics Metadata only | Schematics | PDF 363.9 KB | |
| Operational Description Metadata only | Operational Description | PDF 128.6 KB |
Application Information
| Application ID | 1nKG8ZwFvM3ejOJiYZIlCQ== |
|---|---|
| Final Action Date | 2016-08-07 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0017416041 |
| Model | 3000 |
| Frequency Range | 2412-2462 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | Broadband Digital Transmission System |
| Responsible Party | Simon Chou, General Manager, simonchou@function-g.com , 8775446928 |
| Test Firm | Mark Zhu, Shenzhen Alpha Product Testing Co., Ltd., mark@a-lab.cn  , 86-755-86375552 |
| TCB Email | stuart.beck@nemko.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Limited Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Limited Single Modular Approval. Power output listed is conducted. This device has a 20 MHz and 40 MHz bandwidth mode. Approval is limited to OEM installation only. Compliance of this device in all final host configurations is the responsibility of the Grantee. This device is to be used only for mobile and fixed applications. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 50 cm from all persons and must not be co-located or operating in conjunction with any other transmitter. OEM integrators must be provided with antenna installation instructions and labeling requirements for finished products. OEM integrators and End-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093 and different antenna configurations. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| 1nKG8ZwFvM3ejOJiYZIlCQ== | 2016-08-07 | Original Equipment |
Grants
TCB Grant - Application 1nKG8ZwFvM3ejOJiYZIlCQ==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Nemko North America, INC. 303 River Road Ottawa, Ontario, K1V 1H2 Canada |
Date of Grant: 08/07/2016 Application Dated: 08/07/2016 |
| LigoWave LLC |
| 138 Mountain Brook Dr |
| Canton, GA 30115 |
| Attention: Simon Chou , General Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | V2V-3000 |
| Name of Grantee: | LigoWave LLC |
| Equipment Class: | Digital Transmission System |
| Notes: | Broadband Digital Transmission System |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| MO | 15C | 2412.0 - 2462.0 | 0.9506 |
| Limited Single Modular Approval. Power output listed is conducted. This device has a 20 MHz and 40 MHz bandwidth mode. Approval is limited to OEM installation only. Compliance of this device in all final host configurations is the responsibility of the Grantee. This device is to be used only for mobile and fixed applications. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 50 cm from all persons and must not be co-located or operating in conjunction with any other transmitter. OEM integrators must be provided with antenna installation instructions and labeling requirements for finished products. OEM integrators and End-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093 and different antenna configurations. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application 1nKG8ZwFvM3ejOJiYZIlCQ==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
LigoWave LLC 138 Mountain Brook Dr Canton, GA 30115 United States |
Date of Grant: 08/07/2016 Application Dated: 08/07/2016 |
| Attention: Simon Chou , General Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | V2V-3000 |
| Name of Grantee: | LigoWave LLC |
| Equipment Class: | Digital Transmission System |
| Notes: | Broadband Digital Transmission System |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| MO | 15C | 2412.0 - 2462.0 | 0.9506 |
| Limited Single Modular Approval. Power output listed is conducted. This device has a 20 MHz and 40 MHz bandwidth mode. Approval is limited to OEM installation only. Compliance of this device in all final host configurations is the responsibility of the Grantee. This device is to be used only for mobile and fixed applications. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 50 cm from all persons and must not be co-located or operating in conjunction with any other transmitter. OEM integrators must be provided with antenna installation instructions and labeling requirements for finished products. OEM integrators and End-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093 and different antenna configurations. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
