FCC ID V2V-DLBPROP5
Broadband Digital Transmission System
by LigoWave LLC
Grantee Code: V2V Product Code: DLBPROP5
Latest application date: 2015-09-15
Device Images
FCC ID Device Details
| FCC ID | V2V-DLBPROP5 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | V2V |
| Product Code | DLBPROP5 |
| Applicant Business | LigoWave LLC 🇺🇸 |
| Related Domains |  function-g.com |
| Equipment Class | Broadband Digital Transmission System |
| Test Firm | Shenzhen Alpha Product Testing Co., Ltd. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 5180-5240 MHz | Original Equipment | 2015-09-15 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User manual | Users Manual | 2015-09-15 | PDF 617.8 KB |
| Internal photos | Internal Photos | 2015-09-15 | PDF 260.4 KB |
| External photos | External Photos | 2015-09-15 | PDF 371.1 KB |
| Label | ID Label/Location Info | 2015-09-15 | PDF 95.4 KB |
| Test setup | Test Setup Photos | 2015-09-15 | PDF 228.7 KB |
| Test report | Test Report | 2015-09-15 | PDF 4.5 MB |
| Cover letter | Cover Letter(s) | 2015-09-15 | PDF 161.8 KB |
| RF Exposure | RF Exposure Info | 2015-09-15 | PDF 40.9 KB |
| Block Diagram Metadata only | Block Diagram | PDF 79.8 KB | |
| Schematics Metadata only | Schematics | PDF 198.1 KB | |
| Operational Description Metadata only | Operational Description | PDF 123 KB |
Application Information
| Application ID | UnjJ0j19FU6v5INg+l2D2A== |
|---|---|
| Final Action Date | 2015-09-15 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0017416041 |
| Model | DLBPROP5 |
| Frequency Range | 5180-5240 MHz |
| Equipment Class | NII - Unlicensed National Information Infrastructure TX |
| Device Description | Broadband Digital Transmission System |
| Responsible Party | Simon Chou, General Manager, simonchou@function-g.com , 8775446928 |
| Test Firm | Mark Zhu, Shenzhen Alpha Product Testing Co., Ltd., mark@a-lab.cn  , 86-755-86375552 |
| TCB Email | stuart.beck@nemko.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power listed is aggregate conducted output power. This device has a 20 MHz and 40 MHz bandwidth mode, and intended for fixed point-to-point operations with the specific antennas in MIMO configurations as described in this filing. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 50 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| UnjJ0j19FU6v5INg+l2D2A== | 2015-09-15 | Original Equipment |
Equipment Authorization
Grants
TCB Grant - Application UnjJ0j19FU6v5INg+l2D2A==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Nemko North America, INC. 303 River Road Ottawa, Ontario, K1V 1H2 Canada |
Date of Grant: 09/15/2015 Application Dated: 09/15/2015 |
| LigoWave LLC |
| 138 Mountain Brook Dr |
| Canton, GA 30115 |
| Attention: Simon Chou , General Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | V2V-DLBPROP5 |
| Name of Grantee: | LigoWave LLC |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Broadband Digital Transmission System |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 MO | 15E | 5180.0 - 5240.0 | 0.414 | ||
| 38 MO | 15E | 5745.0 - 5825.0 | 0.669 |
| Power listed is aggregate conducted output power. This device has a 20 MHz and 40 MHz bandwidth mode, and intended for fixed point-to-point operations with the specific antennas in MIMO configurations as described in this filing. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 50 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application UnjJ0j19FU6v5INg+l2D2A==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
LigoWave LLC 138 Mountain Brook Dr Canton, GA 30115 United States |
Date of Grant: 09/15/2015 Application Dated: 09/15/2015 |
| Attention: Simon Chou , General Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | V2V-DLBPROP5 |
| Name of Grantee: | LigoWave LLC |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Broadband Digital Transmission System |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 MO | 15E | 5180.0 - 5240.0 | 0.414 | ||
| 38 MO | 15E | 5745.0 - 5825.0 | 0.669 |
| Power listed is aggregate conducted output power. This device has a 20 MHz and 40 MHz bandwidth mode, and intended for fixed point-to-point operations with the specific antennas in MIMO configurations as described in this filing. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 50 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
