FCC ID V5FDDL001
Low Power Indoor Cellular Remote Unit
by Deltanode Solutions AB
Grantee Code: V5F Product Code: DDL001
Latest application date: 2016-09-13
Device Images
FCC ID Device Details
| FCC ID | V5FDDL001 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | V5F |
| Product Code | DDL001 |
| Applicant Business | Deltanode Solutions AB 🇸🇪 |
| Related Domains |  deltanode.com |
| Equipment Class | Low Power Indoor Cellular Remote Unit |
| Test Firm | Compliance Testing, LLC |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 728-756 MHz | Original Equipment | 2016-09-13 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2016-09-13 | PDF 2.7 MB |
| Internal Photos | Internal Photos | 2016-09-13 | PDF 1 MB |
| External Photos | External Photos | 2016-09-13 | PDF 1.9 MB |
| Label | ID Label/Location Info | 2016-09-13 | PDF 436.1 KB |
| Label Location | ID Label/Location Info | 2016-09-13 | PDF 698.8 KB |
| Test Setup Photos | Test Setup Photos | 2016-09-13 | PDF 304.1 KB |
| Annex A_Part 20 | Test Report | 2016-09-13 | PDF 169.9 KB |
| Annex B_Part 20 | Test Report | 2016-09-13 | PDF 493 KB |
| Annex C_Part 20 | Test Report | 2016-09-13 | PDF 903.3 KB |
| Annex D_Part 20 | Test Report | 2016-09-13 | PDF 822 KB |
| Annex E_Part 20 | Test Report | 2016-09-13 | PDF 257.9 KB |
| FCC Part 1.1310 Test Report | RF Exposure Info | 2016-09-13 | PDF 374.9 KB |
| FCC Part 20 Test Report | Test Report | 2016-09-13 | PDF 418 KB |
| Agent Authorization | Cover Letter(s) | 2016-09-13 | PDF 90.6 KB |
| Confidentiality Request | Cover Letter(s) | 2016-09-13 | PDF 99.8 KB |
| MPE | Cover Letter(s) | 2016-09-13 | PDF 141.5 KB |
| Warning Label Statement | Cover Letter(s) | 2016-09-13 | PDF 131.7 KB |
| Block Diagram Metadata only | Block Diagram | PDF 481.9 KB | |
| Schematics Metadata only | Schematics | PDF 771.9 KB | |
| Operational Description Metadata only | Operational Description | PDF 208.5 KB | |
| Parts List Metadata only | Parts List/Tune Up Info | PDF 1.9 MB | |
| Tune Up Procedure Metadata only | Parts List/Tune Up Info | PDF 383.2 KB |
Application Information
| Application ID | V7vEWa5Cbcpy8Sly6jYv9g== |
|---|---|
| Final Action Date | 2016-09-13 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0017536640 |
| Model | DDL001 |
| Frequency Range | 728-756 MHz |
| Equipment Class | B2I - Part 20 Industrial Booster (CMRS) |
| Device Description | Low Power Indoor Cellular Remote Unit |
| Responsible Party | Daniel Kerek, Senior Systems Engineer, daniel.kerek@deltanode.com , +46707985220 |
| Agent | Amanda Amanda Amanda, Compliance Testing, LLC, 480-926-3100 |
| Test Firm | Michael Schafer, Compliance Testing, LLC, michaels@compliancetesting.com  , 480-926-3100 |
| TCB Email | amandar@compliancetesting.com |
| TCB Scope | B1: Commercial mobile radio services equipment in the following 47 CFR Parts 20, 22 (cellular), 24,25 (below 3 GHz) & 27 |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power output listed is conducted. The antenna(s) used for this transmitting device must be professionally installed to provide a separation distance of at least 20 cm from all persons. Installers and end-users must be provided with antenna installation instructions and transmitting device operating conditions for satisfying RF exposure compliance. The installation height of the antenna for AWS band (1700/2100 MHz) operation is limited to 10 meters above ground for compliance with 47 CFR 27.50. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| V7vEWa5Cbcpy8Sly6jYv9g== | 2016-09-13 | Original Equipment |
Equipment Authorization
| Frequency | Output | Emission | Rules |
|---|---|---|---|
| 728-756 MHz | 0.528 | G7D | 27 |
| 728-756 MHz | 0.528 | G7W | 27 |
| 728-756 MHz | 0.528 | GXW | 27 |
| 869-894 MHz | 0.447 | F9W | 22H |
| 869-894 MHz | 0.447 | G7D | 22H |
| 869-894 MHz | 0.447 | G7W | 22H |
| 869-894 MHz | 0.447 | GXW | 22H |
| 1930-1995 MHz | 0.604 | G7D | 24D |
| 1930-1995 MHz | 0.604 | G7W | 24D |
| 1930-1995 MHz | 0.604 | GXW | 24D |
| 1930-1995 MHz | 0.604 | F9W | 24D |
| 2110-2180 MHz | 0.469 | F9W | 27 |
| 2110-2180 MHz | 0.469 | G7D | 27 |
| 2110-2180 MHz | 0.469 | G7W | 27 |
| 2110-2180 MHz | 0.469 | GXW | 27 |
Grants
TCB Grant - Application V7vEWa5Cbcpy8Sly6jYv9g==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Compliance Testing, LLC 1724 S. Nevada Way Mesa, AZ 85204 |
Date of Grant: 09/13/2016 Application Dated: 09/13/2016 |
| Deltanode Solutions AB |
| Hammarby Fabriksvag 61 |
| Stockholm, SE-120 30 Sweden |
| Attention: Daniel Kerek , Senior Systems Engineer |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | V5FDDL001 |
| Name of Grantee: | Deltanode Solutions AB |
| Equipment Class: | Part 20 Industrial Booster (CMRS) |
| Notes: | Low Power Indoor Cellular Remote Unit |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 27 | 728.0 - 756.0 | 0.528 | F9W | ||
| 27 | 728.0 - 756.0 | 0.528 | G7D | ||
| 27 | 728.0 - 756.0 | 0.528 | G7W | ||
| 27 | 728.0 - 756.0 | 0.528 | GXW | ||
| 22H | 869.0 - 894.0 | 0.447 | F9W | ||
| 22H | 869.0 - 894.0 | 0.447 | G7D | ||
| 22H | 869.0 - 894.0 | 0.447 | G7W | ||
| 22H | 869.0 - 894.0 | 0.447 | GXW | ||
| 24D | 1930.0 - 1995.0 | 0.604 | F9W | ||
| 24D | 1930.0 - 1995.0 | 0.604 | G7D | ||
| 24D | 1930.0 - 1995.0 | 0.604 | G7W | ||
| 24D | 1930.0 - 1995.0 | 0.604 | GXW | ||
| 27 | 2110.0 - 2180.0 | 0.469 | F9W | ||
| 27 | 2110.0 - 2180.0 | 0.469 | G7D | ||
| 27 | 2110.0 - 2180.0 | 0.469 | G7W | ||
| 27 | 2110.0 - 2180.0 | 0.469 | GXW |
| Power output listed is conducted. The antenna(s) used for this transmitting device must be professionally installed to provide a separation distance of at least 20 cm from all persons. Installers and end-users must be provided with antenna installation instructions and transmitting device operating conditions for satisfying RF exposure compliance. The installation height of the antenna for AWS band (1700/2100 MHz) operation is limited to 10 meters above ground for compliance with 47 CFR 27.50. |
EAS Grant - Application V7vEWa5Cbcpy8Sly6jYv9g==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Deltanode Solutions AB Hammarby Fabriksvag 61 Stockholm, SE-120 30 Sweden |
Date of Grant: 09/13/2016 Application Dated: 09/13/2016 |
| Attention: Daniel Kerek , Senior Systems Engineer |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | V5FDDL001 |
| Name of Grantee: | Deltanode Solutions AB |
| Equipment Class: | Part 20 Industrial Booster (CMRS) |
| Notes: | Low Power Indoor Cellular Remote Unit |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 27 | 728.0 - 756.0 | 0.528 | F9W | ||
| 27 | 728.0 - 756.0 | 0.528 | G7D | ||
| 27 | 728.0 - 756.0 | 0.528 | G7W | ||
| 27 | 728.0 - 756.0 | 0.528 | GXW | ||
| 22H | 869.0 - 894.0 | 0.447 | F9W | ||
| 22H | 869.0 - 894.0 | 0.447 | G7D | ||
| 22H | 869.0 - 894.0 | 0.447 | G7W | ||
| 22H | 869.0 - 894.0 | 0.447 | GXW | ||
| 24D | 1930.0 - 1995.0 | 0.604 | F9W | ||
| 24D | 1930.0 - 1995.0 | 0.604 | G7D | ||
| 24D | 1930.0 - 1995.0 | 0.604 | G7W | ||
| 24D | 1930.0 - 1995.0 | 0.604 | GXW | ||
| 27 | 2110.0 - 2180.0 | 0.469 | F9W | ||
| 27 | 2110.0 - 2180.0 | 0.469 | G7D | ||
| 27 | 2110.0 - 2180.0 | 0.469 | G7W | ||
| 27 | 2110.0 - 2180.0 | 0.469 | GXW |
| Power output listed is conducted. The antenna(s) used for this transmitting device must be professionally installed to provide a separation distance of at least 20 cm from all persons. Installers and end-users must be provided with antenna installation instructions and transmitting device operating conditions for satisfying RF exposure compliance. The installation height of the antenna for AWS band (1700/2100 MHz) operation is limited to 10 meters above ground for compliance with 47 CFR 27.50. |
| Mail To: |
