AR8 Smart Tablet Label Diagram - FCC ID V5PAR8

FCC ID V5PAR8

Label

Smart Tablet

by PAX Technology Limited

Document preview loads when visible.

Document Details

FCC IDV5PAR8
Document ID4234248
Document TypeID Label/Location Info
DescriptionLabel
ApplicantPAX Technology Limited
Equipment ClassSmart Tablet
Product CodeAR8
Application ID7EOaeknNTXLl9Mx36evHCQ==
Application PurposeOriginal Equipment
Application Date2019-04-11
Frequency Range13.56 MHz
FRN0017536285
Test FirmSporton International (Shenzhen) Inc.
Certified ByMichael Lin Vice President
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date10/06/2019
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2019-04-10
Available2019-04-11
Created2018-12-19
Modified2018-12-19
Pages1
File TypeAdobe Acrobat PDF
File Size51727
File SHA-25602eb8473d4988bfc0be4e8847004c90414a898f4a7423d6fbdda577287635352
FCC.gov SourcesFCC.gov 4234248, FCC.gov 4234171, FCC.gov 4234141, FCC.gov 4234108, FCC.gov 4232306
