A3 150Mbps Wireless Range Extender Teardown... - FCC ID V7TA3

FCC ID V7TA3

Internal Photos

150Mbps Wireless Range Extender

by SHENZHEN TENDA TECHNOLOGY CO., LTD.

Document preview loads when visible.

Document Details

FCC IDV7TA3
Document ID1754766
Document TypeInternal Photos
DescriptionInternal Photos
Document TitleInternal Photos
ApplicantSHENZHEN TENDA TECHNOLOGY CO., LTD.
Equipment Class150Mbps Wireless Range Extender
Product CodeA3
Application IDlvIrBQ1AJgZdYPbNePZK4g==
Application PurposeOriginal Equipment
Application Date2012-07-28
Frequency Range2412-2462 MHz
FRN0017645623
Test FirmBay Area Compliance Laboratories Corp. (Dongguan)
Certified ByLiao,Bin
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2012-07-28
Available2012-07-28
Created2012-07-29
Modified2012-07-29
Pages2
File TypeAdobe Acrobat PDF
File Size189246
File SHA-2561d241f39854d6a40927e1a8127cf07a0e889331dea8532cf527a8d46a8aabd64
PDF Metadata Authorjohnc
PDF Metadata CreatorPScript5.dll Version 5.2.2
PDF Metadata ProducerAcrobat Distiller 7.0 (Windows)
FCC.gov SourcesFCC.gov 1754766, FCC.gov 1754759
