N3 Wireless N Broadband Router Teardown Internal... - FCC ID V7TN3

FCC ID V7TN3

Internal Photos

Wireless N Broadband Router

by SHENZHEN TENDA TECHNOLOGY CO., LTD.

Document preview loads when visible.

Document Details

FCC IDV7TN3
Document ID1759497
Document TypeInternal Photos
DescriptionInternal Photos
Document TitleInternal Photos
ApplicantSHENZHEN TENDA TECHNOLOGY CO., LTD.
Equipment ClassWireless N Broadband Router
Product CodeN3
Application IDcmszyXsROZY81hfo2mNlvw==
Application PurposeOriginal Equipment
Application Date2012-08-03
Frequency Range2412-2462 MHz
FRN0017645623
Test FirmBay Area Compliance Laboratories Corp. (Dongguan)
Certified ByLiao Bin
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2012-08-03
Available2012-08-03
Created2012-08-04
Modified2012-08-04
Pages2
File TypeAdobe Acrobat PDF
File Size142625
File SHA-256e0dc9f29a4e43272ff5d83553a29afd7eb2fb92b065e89c9003ef1d02ed38ae6
PDF Metadata Authorjohnc
PDF Metadata CreatorPScript5.dll Version 5.2.2
PDF Metadata ProducerAcrobat Distiller 7.0 (Windows)
FCC.gov SourcesFCC.gov 1759497, FCC.gov 1759490
