FCC ID V84HPA8000B-54
Amateur Radio Power Amplifier 1 kW / 1.8 - 54 MHz
by Hilberling GmbH RF Laboratories
Grantee Code: V84 Product Code: HPA8000B54
Latest application date: 2017-04-24
Device Images
FCC ID Device Details
| FCC ID | V84HPA8000B-54 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | V84 |
| Product Code | HPA8000B54 |
| Applicant Business | Hilberling GmbH RF Laboratories 🇩🇪 |
| Related Domains |  hilberling.de |
| Equipment Class | Amateur Radio Power Amplifier 1 kW / 1.8 - 54 MHz |
| Test Firm | EMCCons DR. RASEK GmbH & Co. KG |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 1.8-54 MHz | Original Equipment | 2017-04-24 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2017-04-24 | PDF 3.9 MB |
| Internal Photos | Internal Photos | 2017-04-24 | PDF 3.3 MB |
| External Photos | External Photos | 2017-04-24 | PDF 788.7 KB |
| ID Label and Location | ID Label/Location Info | 2017-04-24 | PDF 877.7 KB |
| Operational description | Operational Description | 2017-04-24 | PDF 427.8 KB |
| Test Setup Photos | Test Setup Photos | 2017-04-24 | PDF 1.3 MB |
| Test Report | Test Report | 2017-04-24 | PDF 4.6 MB |
| Confidentiality Request | Cover Letter(s) | 2017-04-24 | PDF 254.2 KB |
| Block diagram Metadata only | Block Diagram | PDF 330.3 KB | |
| Schematics Part 1 Metadata only | Schematics | PDF 156.9 KB | |
| Schematics Part 2 Metadata only | Schematics | PDF 157.7 KB | |
| Schematics Part 3 Metadata only | Schematics | PDF 1.8 MB | |
| Schematics Part 4 Metadata only | Schematics | PDF 37.7 KB | |
| Schematics Part 5 Metadata only | Schematics | PDF 224.5 KB | |
| Schematics Part 6 Metadata only | Schematics | PDF 167 KB | |
| Schematics Part 7 Metadata only | Schematics | PDF 138.3 KB | |
| Schematics Part 8 Metadata only | Schematics | PDF 1.1 MB | |
| Tune Up Info, Parts list Metadata only | Parts List/Tune Up Info | PDF 1.2 MB |
Application Information
| Application ID | rlsfD1umZvm4MxFNa2/v3A== |
|---|---|
| Final Action Date | 2017-04-24 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0017694365 |
| Model | HPA8000B-54 |
| Equipment Class | JBP - Part 15 Class B Computing Device Peripheral |
| Device Description | Amateur Radio Power Amplifier 1 kW / 1.8 - 54 MHz |
| Responsible Party | Jan Hauschildt, Executive Officer Production, info@hilberling.de , (04331) 2 01 71-0 |
| Test Firm | Reinhard Sauerchell, EMCCons DR. RASEK GmbH & Co. KG, emc.cons@emcc.de  , 49-9194-72279-01 |
| TCB Email | g.proelss@emcc.de |
| TCB Scope | A1: Low Power Transmitters below 1 GHz (except Spread Spectrum), Unintentional Radiators, EAS (Part 11) & Consumer ISM devices |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| rlsfD1umZvm4MxFNa2/v3A== | 2017-04-24 | Original Equipment |
| M5Byu7BUpkWihPsniJwZPw== | 2017-04-24 | Original Equipment |
Equipment Authorization
Grants
TCB Grant - Application rlsfD1umZvm4MxFNa2/v3A==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
EMCCons DR RASEK GmbH & Co. KG Stoernhofer Berg 15 Unterleinleiter, 91364 Germany |
Date of Grant: 04/24/2017 Application Dated: 04/24/2017 |
| Hilberling GmbH RF Laboratories |
| Heinrich-Hertz-Strasse 2 |
| Schacht-Audorf, 24790 Germany |
| Attention: Jan Hauschildt , Executive Officer Production |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | V84HPA8000B-54 |
| Name of Grantee: | Hilberling GmbH RF Laboratories |
| Equipment Class: | Part 15 Class B Computing Device Peripheral |
| Notes: | Amateur Radio Power Amplifier 1 kW / 1.8 - 54 MHz |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 19 | 15B | - |
| 19: | This device must be marketed with a shielded interface cable which incorporates ferrite cores equal in quantity and type to those used during Certification testing. |
