FCC ID VBNFXCB-01

Flexi Multiradio BTS (FXCB)

by Nokia Solutions and Networks

Grantee Code: VBN   Product Code: FXCB01
Latest application date: 2021-10-22

Device Images

FCC ID VBNFXCB-01 Test Setup Photos
Test Setup Photos
FCC ID VBNFXCB-01 Test Setup Photos
Test Setup Photos
FCC ID VBNFXCB-01 Test Setup Photos
Test Setup Photos

FCC ID Device Details

FCC IDVBNFXCB-01
Mirrorsfcc.id | gov | fccid.ai
Grantee CodeVBN
Product CodeFXCB01
Applicant BusinessNokia Solutions and Networks 🇺🇸
Related Domains nokia.com
Equipment ClassFlexi Multiradio BTS (FXCB)
Test FirmNokia, Global Product Compliance Lab

Operating Frequencies

Frequency RangeApplication PurposeFinal Action Date
869-894 MHzClass II permissive change or modification of presently authorized equipment2021-10-22
869-894 MHzClass II permissive change or modification of presently authorized equipment2016-06-27
869-894 MHzOriginal Equipment2013-04-27

Exhibits

DocumentTypeAvailableFile
external photosExternal Photos2013-04-27PDF 1.3 MB
label and locationID Label/Location Info2013-04-27PDF 94.3 KB
TSUP Exhibit 3Test Setup Photos2021-10-22PDF 2.1 MB
Test Set Up PhotosTest Setup Photos2016-06-27PDF 567.9 KB
Test Report Exhibit 4Test Report2021-10-22PDF 5.3 MB
Test ReportTest Report2016-06-27PDF 5.5 MB
test reportTest Report2013-04-27PDF 564.4 KB
C2PC LetterCover Letter(s)2021-10-22PDF 87.6 KB
Cover Letter Exhibit 2Cover Letter(s)2021-10-22PDF 80.7 KB
LOA LetterCover Letter(s)2021-10-22PDF 61.7 KB
Authority to Act as AgentCover Letter(s)2016-06-27PDF 12.6 KB
Class II Permissive ChangeCover Letter(s)2016-06-27PDF 11.3 KB
NDA letterCover Letter(s)2013-04-27PDF 20 KB
agent letterCover Letter(s)2013-04-27PDF 54.1 KB
confidential letterCover Letter(s)2013-04-27PDF 49.7 KB

Application Information

Application IDE86Fy7r0S22J37BQmIpm0g==
Final Action Date2021-10-22
Application PurposeClass II permissive change or modification of presently authorized equipment
Applicant FRN0016412652
ModelFXCB-01
Frequency Range869-894 MHz
Equipment ClassTNB - Licensed Non-Broadcast Station Transmitter
Device DescriptionFlexi Multiradio BTS (FXCB)
Responsible PartySteve Mitchell, steve.mitchell@nokia.com , 972-936-7500
Test FirmHernan Noguchi, Nokia, Global Product Compliance Lab, hernan.noguchi@nokia-bell-labs.com , 908-582-7160
TCB Emailtei@timcoengr.com
TCB ScopeB1: Commercial mobile radio services equipment in the following 47 CFR Parts 20, 22 (cellular), 24,25 (below 3 GHz) & 27
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Cognitive RadioNo
Authorization WaiverNo
Authorization Waiver ApprovedNo
Section 5301 CertificationYes
Related OET Knowledge DataBase InquiryNo
Grant CommentsOutput is conducted. The antenna(s) used for this transmitter must be fixed-mounted on outdoor permanent structures. RF exposure compliance is addressed at the time of licensing, as required by the responsible FCC Bureau(s), including antenna co-location requirements of §1.1307(b)(3). Class II Permissive Change to add 5G-NR bandwidths of 5 and 10MHz.

Applications

Application IDDatePurpose
E86Fy7r0S22J37BQmIpm0g==2021-10-22Class II permissive change or modification of presently authorized equipment
W+hGwDvydKI7h4/Sk9ER+Q==2016-06-27Class II permissive change or modification of presently authorized equipment
3NL06usbhggZ9W86Km5x9A==2013-04-27Original Equipment

Equipment Authorization

FrequencyOutputToleranceEmissionRulesGrant Notes
869-894 MHz801.5ppm9M28W7W22HMO
869-894 MHz801.5ppm300KGXW22H
869-894 MHz801.5ppm300KG7W22HMO
869-894 MHz801.5ppm300KG7W22H
869-894 MHz801.5ppm300KD7W22HMO
869-894 MHz801.5ppm300KD7W22H
869-894 MHz801.5ppm5M00D7W22HMO
869-894 MHz801.5ppm5M00D7W22H
869-894 MHz801.5ppm1M29F9W22HMO
869-894 MHz801.5ppm1M29F9W22H
869-894 MHz801.5ppm2M93F9W22HMO
869-894 MHz801.5ppm2M93F9W22H
869-894 MHz801.5ppm4M87F9W22HMO
869-894 MHz801.5ppm4M87F9W22H
869-894 MHz801.5ppm9M73F9W22HMO
869-894 MHz801.5ppm9M73F9W22H
869-894 MHz801.5ppm4M47W7W22HMO

Grants

TCB Grant - Application W+hGwDvydKI7h4/Sk9ER+Q==

TCB GRANT OF EQUIPMENT
AUTHORIZATION		 TCB
Certification
Issued Under the Authority of the
Federal Communications Commission
By:

  Nemko North America, INC.
303 River Road
Ottawa, Ontario, K1V 1H2
Canada 		Date of Grant: 06/27/2016

Application Dated: 06/24/2016
Nokia Solutions and Networks
3201 Olympus Blvd
Dallas, TX 75019

Attention: Steve Mitchell

NOT TRANSFERABLE
EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below.

FCC IDENTIFIER:  VBNFXCB-01
Name of Grantee:  Nokia Solutions and Networks
Equipment Class: Licensed Non-Broadcast Station Transmitter
Notes: Cellular Base Station
Grant Notes  FCC Rule Parts Frequency
Range (MHZ) 		Output
Watts 		Frequency
Tolerance 		Emission
Designator
22H 869.0  -  894.0 80.0 1.5  PM 300KGXW
22H 869.0  -  894.0 80.0 1.5  PM 300KG7W
22H 869.0  -  894.0 80.0 1.5  PM 300KD7W
22H 869.0  -  894.0 80.0 1.5  PM 5M00D7W
22H 869.0  -  894.0 80.0 1.5  PM 1M29F9W
22H 869.0  -  894.0 80.0 1.5  PM 2M93F9W
22H 869.0  -  894.0 80.0 1.5  PM 4M87F9W
22H 869.0  -  894.0 80.0 1.5  PM 9M73F9W

Power output listed is conducted. Users and installers must be provided with antenna installation and transmitter operating conditions for satisfying RF exposure compliance. RF exposure compliance may need to be addressed at the time of licensing, as required by the responsible FCC Bureau(s), including antenna co-location requirements of 1.1307(b)(3).

EAS Grant - Application W+hGwDvydKI7h4/Sk9ER+Q==

COPY FEDERAL COMMUNICATIONS
COMMISSION
WASHINGTON, D.C. 20554

GRANT OF EQUIPMENT
AUTHORIZATION		 COPY
Certification

Nokia Solutions and Networks
3201 Olympus Blvd
Dallas, TX 75019
United States 		  Date of Grant: 06/27/2016

Application Dated: 06/24/2016

Attention: Steve Mitchell

NOT TRANSFERABLE
EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below.

FCC IDENTIFIER:  VBNFXCB-01
Name of Grantee:  Nokia Solutions and Networks
Equipment Class: Licensed Non-Broadcast Station Transmitter
Notes: Cellular Base Station
Modular Type: Does not apply
Grant Notes  FCC Rule Parts Frequency
Range (MHZ) 		Output
Watts 		Frequency
Tolerance 		Emission
Designator
22H 869.0  -  894.0 80.0 1.5  PM 300KGXW
22H 869.0  -  894.0 80.0 1.5  PM 300KG7W
22H 869.0  -  894.0 80.0 1.5  PM 300KD7W
22H 869.0  -  894.0 80.0 1.5  PM 5M00D7W
22H 869.0  -  894.0 80.0 1.5  PM 1M29F9W
22H 869.0  -  894.0 80.0 1.5  PM 2M93F9W
22H 869.0  -  894.0 80.0 1.5  PM 4M87F9W
22H 869.0  -  894.0 80.0 1.5  PM 9M73F9W

Power output listed is conducted. Users and installers must be provided with antenna installation and transmitter operating conditions for satisfying RF exposure compliance. RF exposure compliance may need to be addressed at the time of licensing, as required by the responsible FCC Bureau(s), including antenna co-location requirements of 1.1307(b)(3).



TCB Grant - Application E86Fy7r0S22J37BQmIpm0g==

Mail To:
TCB GRANT OF EQUIPMENT
AUTHORIZATION		 TCB
Certification
Issued Under the Authority of the
Federal Communications Commission
By:

  Timco Engineering, Inc.
849 NW State Road 45
Newberry, FL 32669
 Date of Grant: 10/22/2021

Application Dated: 10/22/2021
Nokia Solutions and Networks
3201 Olympus Blvd
Dallas, TX 75019

Attention: Steve Mitchell

NOT TRANSFERABLE
EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below.

FCC IDENTIFIER:  VBNFXCB-01
Name of Grantee:  Nokia Solutions and Networks
Equipment Class: Licensed Non-Broadcast Station Transmitter
Notes: Flexi Multiradio BTS (FXCB)
Grant Notes  FCC Rule Parts Frequency
Range (MHZ) 		Output
Watts 		Frequency
Tolerance 		Emission
Designator
MO 22H 869.0  -  894.0 80.0 1.5  PM 300KGXW
MO 22H 869.0  -  894.0 80.0 1.5  PM 300KG7W
MO 22H 869.0  -  894.0 80.0 1.5  PM 300KD7W
MO 22H 869.0  -  894.0 80.0 1.5  PM 5M00D7W
MO 22H 869.0  -  894.0 80.0 1.5  PM 1M29F9W
MO 22H 869.0  -  894.0 80.0 1.5  PM 2M93F9W
MO 22H 869.0  -  894.0 80.0 1.5  PM 4M87F9W
MO 22H 869.0  -  894.0 80.0 1.5  PM 9M73F9W
MO 22H 869.0  -  894.0 80.0 1.5  PM 4M47W7W
MO 22H 869.0  -  894.0 80.0 1.5  PM 9M28W7W

Output is conducted. The antenna(s) used for this transmitter must be fixed-mounted on outdoor permanent structures. RF exposure compliance is addressed at the time of licensing, as required by the responsible FCC Bureau(s), including antenna co-location requirements of §1.1307(b)(3).

Class II Permissive Change to add 5G-NR bandwidths of 5 and 10MHz.


MO: This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing.

EAS Grant - Application E86Fy7r0S22J37BQmIpm0g==

COPY FEDERAL COMMUNICATIONS
COMMISSION
WASHINGTON, D.C. 20554

GRANT OF EQUIPMENT
AUTHORIZATION		 COPY
Certification

Nokia Solutions and Networks
3201 Olympus Blvd
Dallas, TX 75019
United States 		  Date of Grant: 10/22/2021

Application Dated: 10/22/2021

Attention: Steve Mitchell

NOT TRANSFERABLE
EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below.

FCC IDENTIFIER:  VBNFXCB-01
Name of Grantee:  Nokia Solutions and Networks
Equipment Class: Licensed Non-Broadcast Station Transmitter
Notes: Flexi Multiradio BTS (FXCB)
Modular Type: Does not apply
Grant Notes  FCC Rule Parts Frequency
Range (MHZ) 		Output
Watts 		Frequency
Tolerance 		Emission
Designator
MO 22H 869.0  -  894.0 80.0 1.5  PM 300KGXW
MO 22H 869.0  -  894.0 80.0 1.5  PM 300KG7W
MO 22H 869.0  -  894.0 80.0 1.5  PM 300KD7W
MO 22H 869.0  -  894.0 80.0 1.5  PM 5M00D7W
MO 22H 869.0  -  894.0 80.0 1.5  PM 1M29F9W
MO 22H 869.0  -  894.0 80.0 1.5  PM 2M93F9W
MO 22H 869.0  -  894.0 80.0 1.5  PM 4M87F9W
MO 22H 869.0  -  894.0 80.0 1.5  PM 9M73F9W
MO 22H 869.0  -  894.0 80.0 1.5  PM 4M47W7W
MO 22H 869.0  -  894.0 80.0 1.5  PM 9M28W7W

Output is conducted. The antenna(s) used for this transmitter must be fixed-mounted on outdoor permanent structures. RF exposure compliance is addressed at the time of licensing, as required by the responsible FCC Bureau(s), including antenna co-location requirements of §1.1307(b)(3).

Class II Permissive Change to add 5G-NR bandwidths of 5 and 10MHz.


MO: This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing.

TCB Grant - Application 3NL06usbhggZ9W86Km5x9A==

Mail To:
TCB GRANT OF EQUIPMENT
AUTHORIZATION		 TCB
Certification
Issued Under the Authority of the
Federal Communications Commission
By:

  Nemko Canada Inc.
303 River Road
Ottawa, Ontario, K1V 1H2
Canada 		Date of Grant: 04/27/2013

Application Dated: 04/27/2013
Nokia Solutions and Networks
6000 Connection Drive
Irving, TX 75039

Attention: Steve Mitchell

NOT TRANSFERABLE
EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below.

FCC IDENTIFIER:  VBNFXCB-01
Name of Grantee:  Nokia Solutions and Networks
Equipment Class: Licensed Non-Broadcast Station Transmitter
Notes: Cellular Base Station
Grant Notes  FCC Rule Parts Frequency
Range (MHZ) 		Output
Watts 		Frequency
Tolerance 		Emission
Designator
22H 869.0  -  894.0 80.0 1.5  PM 300KGXW
22H 869.0  -  894.0 80.0 1.5  PM 300KG7W
22H 869.0  -  894.0 80.0 1.5  PM 300KD7W
22H 869.0  -  894.0 80.0 1.5  PM 5M00D7W

Output is conducted. The antenna(s) used for this transmitter must be fixed-mounted on outdoor permanent structures. RF exposure compliance is addressed at the time of licensing, as required by the responsible FCC Bureau(s), including antenna co-location requirements of §1.1307(b)(3).

EAS Grant - Application 3NL06usbhggZ9W86Km5x9A==

COPY FEDERAL COMMUNICATIONS
COMMISSION
WASHINGTON, D.C. 20554

GRANT OF EQUIPMENT
AUTHORIZATION		 COPY
Certification

Nokia Solutions and Networks
6000 Connection Drive
Irving, TX 75039
United States 		  Date of Grant: 04/27/2013

Application Dated: 04/27/2013

Attention: Steve Mitchell

NOT TRANSFERABLE
EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below.

FCC IDENTIFIER:  VBNFXCB-01
Name of Grantee:  Nokia Solutions and Networks
Equipment Class: Licensed Non-Broadcast Station Transmitter
Notes: Cellular Base Station
Modular Type: Does not apply
Grant Notes  FCC Rule Parts Frequency
Range (MHZ) 		Output
Watts 		Frequency
Tolerance 		Emission
Designator
22H 869.0  -  894.0 80.0 1.5  PM 300KGXW
22H 869.0  -  894.0 80.0 1.5  PM 300KG7W
22H 869.0  -  894.0 80.0 1.5  PM 300KD7W
22H 869.0  -  894.0 80.0 1.5  PM 5M00D7W

Output is conducted. The antenna(s) used for this transmitter must be fixed-mounted on outdoor permanent structures. RF exposure compliance is addressed at the time of licensing, as required by the responsible FCC Bureau(s), including antenna co-location requirements of §1.1307(b)(3).
