FCC ID VG5WIN7258
WiMAX pBST base station transceiver
by Siemens Canada Limited
Grantee Code: VG5 Product Code: WIN7258
Latest application date: 2016-09-06
Device Images
FCC ID Device Details
| FCC ID | VG5WIN7258 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | VG5 |
| Product Code | WIN7258 |
| Applicant Business | Siemens Canada Limited 🇨🇦 |
| Related Domains |  siemens.com |
| Equipment Class | WiMAX pBST base station transceiver |
| Test Firm | Hermon Laboratories Ltd. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 5732.5-5842.5 MHz | Original Equipment | 2016-09-06 |
| 5728-5846 MHz | Original Equipment | 2012-11-05 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Users Manual | Users Manual | 2016-09-06 | PDF 3 MB |
| user manual | Users Manual | 2012-11-05 | PDF 2.4 MB |
| Internal Photos | Internal Photos | 2016-09-06 | PDF 1,011.5 KB |
| Int. photos | Internal Photos | 2012-11-05 | PDF 1,011.4 KB |
| External Photos | External Photos | 2016-09-06 | PDF 78.8 KB |
| Ext. photos | External Photos | 2012-11-05 | PDF 78.8 KB |
| ID Label/Location Info | ID Label/Location Info | 2016-09-06 | PDF 217.8 KB |
| label | ID Label/Location Info | 2012-11-05 | PDF 204.9 KB |
| Test Setup Photos | Test Setup Photos | 2016-09-06 | PDF 1.8 MB |
| Test setup photo | Test Setup Photos | 2012-11-05 | PDF 1.8 MB |
| Test Report | Test Report | 2016-09-06 | PDF 789.2 KB |
| Test report | Test Report | 2012-11-05 | PDF 1.9 MB |
| Antenna_ANT0074_16dBi | Cover Letter(s) | 2016-09-06 | PDF 91.7 KB |
| Antenna_ANT0076_9.5dBi | Cover Letter(s) | 2016-09-06 | PDF 46.3 KB |
| Authorization letter | Cover Letter(s) | 2016-09-06 | PDF 35.3 KB |
| Class II Permissive Change | Cover Letter(s) | 2016-09-06 | PDF 20.3 KB |
| Cover letter | Cover Letter(s) | 2016-09-06 | PDF 19.9 KB |
| Declaration of authorization | Cover Letter(s) | 2016-09-06 | PDF 19.9 KB |
| confidentiality | Cover Letter(s) | 2016-09-06 | PDF 18.2 KB |
| Auth letter | Cover Letter(s) | 2012-11-05 | PDF 38.2 KB |
| Conf. letter | Cover Letter(s) | 2012-11-05 | PDF 18.1 KB |
| Cover. decl | Cover Letter(s) | 2012-11-05 | PDF 40.3 KB |
| DoA | Cover Letter(s) | 2012-11-05 | PDF 22.5 KB |
| RF Exposure Info | RF Exposure Info | 2016-09-06 | PDF 50.6 KB |
| RF expo | RF Exposure Info | 2012-11-05 | PDF 51.8 KB |
| Block Diagram Metadata only | Block Diagram | PDF 64.2 KB | |
| Schematics_RF Metadata only | Schematics | PDF 439.2 KB | |
| Schematics_digital Metadata only | Schematics | PDF 352.4 KB | |
| Operational Description Metadata only | Operational Description | PDF 77.2 KB | |
| Software Security Info Metadata only | Operational Description | PDF 47.7 KB |
Application Information
| Application ID | Oz0UOutatQfCkuPikkW4qw== |
|---|---|
| Final Action Date | 2016-09-06 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0016678849 |
| Model | WIN7258 |
| Frequency Range | 5732.5-5842.5 MHz |
| Equipment Class | NII - Unlicensed National Information Infrastructure TX |
| Device Description | WiMAX pBST base station transceiver |
| Responsible Party | Norman Lew, Senior Certification Engineer, norman.lew@siemens.com , 905-482-7217 |
| Technical Contact | Michael Nikishin, Hermon Laboratories Ltd., nikishin@hermonlabs.com  , 972 4626 8440 |
| Non-Technical Contact | Israel Aminov, Siemens Canada Limited, israel.aminov@siemens.com , (905) 482 4558 |
| Test Firm | George Shleimovich, Hermon Laboratories Ltd., George@HERMONLABS.com , 97246268468 |
| TCB Email | certification@telefication.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Class II Permissive Change : This change is only to accommodate with the new U-NII rules. Power output listed is conducted. Only Professional installation is allowed. The antenna used for this device must fixed-mounted on outdoor permanent structures. The antenna(s) used for this transmitter as is in this filling must be installed to provide a separation distance of at least 37 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter other than described in this filing. End-users and installers must be provided with transmitter operating conditions for satisfying RF exposure compliance. |
