XC942KYYPCB Microwave Oven Test Setup Photos - FCC ID VG8XC942KYYPCB
FCC ID VG8XC942KYYPCB
VG8XC942KYYPCB_Test Photos
Microwave Oven
Document preview loads when visible.
Document Details
| FCC ID | VG8XC942KYYPCB |
|---|---|
| Document ID | 3314008 |
| Document Type | Test Setup Photos |
| Description | VG8XC942KYYPCB_Test Photos |
| Document Title | EUT Internal Photos for Model EM720CNN-PM |
| Applicant | Guangdong Midea Kitchen Appliances Manufacturing Co.,Ltd |
| Equipment Class | Microwave Oven |
| Product Code | XC942KYYPCB |
| Application ID | c4awPrIxKiWzWOD5hcrWQQ== |
| Application Purpose | Original Equipment |
| Application Date | 2017-03-15 |
| Frequency Range | 2400-2500 MHz |
| FRN | 0019079995 |
| Test Firm | GD WITOL VACUUM ELECTRONIC EMC TEST LABORATORY |
| Certified By | Jawen Yin EMC Engineer |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2017-03-13 |
| Available | 2017-03-15 |
| Created | 2017-03-09 |
| Modified | 2017-03-09 |
| Pages | 2 |
| File Type | Adobe Acrobat PDF |
| File Size | 510053 |
| File SHA-256 | 40e23ba2cf2825d97055616a55dd64803f68bcccd577c40a084e674a541c7f61 |
| PDF Metadata Author | weifeng |
| PDF Metadata Producer | Microsoft® Word 2016 weifeng |
| FCC.gov Sources | FCC.gov 3314008 |
