FCC ID VGY2832
ADSL2/2+ Security Firewall
by Draytek Corporation
Grantee Code: VGY Product Code: 2832
Latest application date: 2016-09-01
Device Images
FCC ID Device Details
| FCC ID | VGY2832 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | VGY |
| Product Code | 2832 |
| Applicant Business | Draytek Corporation 🇹🇼 |
| Related Domains |  draytek.com |
| Equipment Class | ADSL2/2+ Security Firewall |
| Test Firm | SPORTON International Inc. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2412-2462 MHz | Original Equipment | 2016-09-01 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Users Manual | Users Manual | 2016-09-01 | PDF 709.8 KB |
| Internal Photos | Internal Photos | 2016-09-01 | PDF 2.7 MB |
| External Photos | External Photos | 2016-09-01 | PDF 544.9 KB |
| Label | ID Label/Location Info | 2016-09-01 | PDF 1.3 MB |
| Test Setup Photos | Test Setup Photos | 2016-09-01 | PDF 420.4 KB |
| Test Report | Test Report | 2016-09-01 | PDF 1.9 MB |
| Ad Hoc Mode Function Declaration | Cover Letter(s) | 2016-09-01 | PDF 394.3 KB |
| Confidentiality Request Letter | Cover Letter(s) | 2016-09-01 | PDF 540.4 KB |
| DOC Letter | Cover Letter(s) | 2016-09-01 | PDF 423.8 KB |
| POA | Cover Letter(s) | 2016-09-01 | PDF 594.4 KB |
| MPE Report | RF Exposure Info | 2016-09-01 | PDF 63.8 KB |
| Block Diagram Metadata only | Block Diagram | PDF 43.5 KB | |
| Schematics Metadata only | Schematics | PDF 920.6 KB | |
| Operational Description Metadata only | Operational Description | PDF 11.2 KB |
Application Information
| Application ID | dfNOKqC5kTQDkvaDtTok6Q== |
|---|---|
| Final Action Date | 2016-09-01 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0016678385 |
| Model | 2832 |
| Frequency Range | 2412-2462 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | ADSL2/2+ Security Firewall |
| Responsible Party | Abbott Yu, HW manager, ayu@draytek.com , +886-35972727 |
| Test Firm | Alex Chen, SPORTON International Inc., alex@sporton.com.tw  , 886-3-327-3456 |
| TCB Email | TEI@TIMCOENGR.COM  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power listed is maximum combined output power conducted. Device operates with specific antennas in MIMO configurations as described in this filing. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not transmit simultaneously with any other antenna or transmitter. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device supports 20 and 40MHz bandwidth modes. |
