2865AX 35b & G.Fast Security Router Label Diagram - FCC ID VGY2865AX

FCC ID VGY2865AX

02_Label and location_VGY2865AX_20210401

35b & G.Fast Security Router

by Draytek Corporation

Document preview loads when visible.

Document Details

FCC IDVGY2865AX
Document ID5203118
Document TypeID Label/Location Info
Description02_Label and location_VGY2865AX_20210401
ApplicantDraytek Corporation
Equipment Class35b & G.Fast Security Router
Product Code2865AX
Application ID5FnmAKMpyN7avVf56ZO5IQ==
Application PurposeOriginal Equipment
Application Date2021-04-13
Frequency Range5180-5240 MHz
FRN0016678385
Test FirmUnderwriters Laboratories Taiwan Co., Ltd.
Certified ByAbbott Yu
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2021-04-13
Available2021-04-13
Pages2
File TypeAdobe Acrobat PDF
File Size282485
File SHA-256a6ddbabfb47f7c615687b6dc24df3e943fca668b4eee27f47d823932da8822c3
FCC.gov SourcesFCC.gov 5203118, FCC.gov 5203008
