FCC ID VII-DMGW1
Dome Hub
by Elexa Consumer Products, Inc.
Grantee Code: VII Product Code: DMGW1
Latest application date: 2016-07-04
Device Images
FCC ID Device Details
| FCC ID | VII-DMGW1 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | VII |
| Product Code | DMGW1 |
| Applicant Business | Elexa Consumer Products, Inc. 🇺🇸 |
| Related Domains |  elexausa.com |
| Equipment Class | Dome Hub |
| Test Firm | Shenzhen Anbotek Compliance Laboratory Limited |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2412-2462 MHz | Original Equipment | 2016-07-04 |
| 908.4-916 MHz | Original Equipment | 2016-07-04 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2016-07-04 | PDF 1.4 MB |
| Internal Photos | Internal Photos | 2016-07-04 | PDF 495.8 KB |
| Internal photos | Internal Photos | 2016-07-04 | PDF 495.8 KB |
| External Photos | External Photos | 2016-07-04 | PDF 486.3 KB |
| Label | ID Label/Location Info | 2016-07-04 | PDF 9.4 KB |
| Label Location | ID Label/Location Info | 2016-07-04 | PDF 474.1 KB |
| Label location | ID Label/Location Info | 2016-07-04 | PDF 474.1 KB |
| RF Test Set-up Photos | Test Setup Photos | 2016-07-04 | PDF 1.2 MB |
| RF Test Set-up Photos-wifi | Test Setup Photos | 2016-07-04 | PDF 1.2 MB |
| RF Test Report | Test Report | 2016-07-04 | PDF 1.9 MB |
| RF Test Report-wifi 1 | Test Report | 2016-07-04 | PDF 5.5 MB |
| RF Test Report-wifi 2 | Test Report | 2016-07-04 | PDF 1.6 MB |
| DOC Attestation Letter | Attestation Statements | 2016-07-04 | PDF 12.7 KB |
| Authorization letter | Cover Letter(s) | 2016-07-04 | PDF 83.5 KB |
| DTS Ch12&13 Declaration letter | Cover Letter(s) | 2016-07-04 | PDF 27.7 KB |
| LTC Letter | Cover Letter(s) | 2016-07-04 | PDF 19.8 KB |
| RF Exposure report | RF Exposure Info | 2016-07-04 | PDF 32.9 KB |
| Block Diagram Metadata only | Block Diagram | PDF 106.4 KB | |
| Schematics Metadata only | Schematics | PDF 475.3 KB | |
| Operational Description Metadata only | Operational Description | PDF 173 KB |
Application Information
| Application ID | zT1TMb4BMVTAP85H2KZ5sQ== |
|---|---|
| Final Action Date | 2016-07-04 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0016722274 |
| Model | DMGW1 |
| Frequency Range | 2412-2462 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | Dome Hub |
| Responsible Party | Shristi Sahu, Project Manager, ssahu@elexausa.com , 773-756-5194 |
| Test Firm | Daniel zhu, Shenzhen Anbotek Compliance Laboratory Limited, Daniel.zhu@anbotek.com  , 86-755-26014771 |
| TCB Email | tcb@siemic.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power listed is the maximum conducted output power. Device is 2X2 MIMO. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi- transmitter product procedures. End-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. Device contains 20 and 40 MHz signal bandwidth. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| zT1TMb4BMVTAP85H2KZ5sQ== | 2016-07-04 | Original Equipment |
| s6kFBhU5jQJ7wTOBZSxQtw== | 2016-07-04 | Original Equipment |
Equipment Authorization
Grants
TCB Grant - Application zT1TMb4BMVTAP85H2KZ5sQ==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Bureau Veritas Consumer Products Services, Inc. 775 Montague Expressway Milpitas, CA 95035 |
Date of Grant: 07/04/2016 Application Dated: 07/04/2016 |
| Elexa Consumer Products, Inc. |
| 2275 HALF DAY RD STE 160 |
| STE 160 |
| Bannockburn, IL 60015 |
| Attention: Shristi Sahu , Project Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | VII-DMGW1 |
| Name of Grantee: | Elexa Consumer Products, Inc. |
| Equipment Class: | Digital Transmission System |
| Notes: | Dome Hub |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15C | 2412.0 - 2462.0 | 0.417 |
| Power listed is the maximum conducted output power. Device is 2X2 MIMO. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi- transmitter product procedures. End-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. Device contains 20 and 40 MHz signal bandwidth. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application zT1TMb4BMVTAP85H2KZ5sQ==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Elexa Consumer Products, Inc. 2275 HALF DAY RD STE 160 STE 160 Bannockburn, IL 60015 United States |
Date of Grant: 07/04/2016 Application Dated: 07/04/2016 |
| Attention: Shristi Sahu , Project Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | VII-DMGW1 |
| Name of Grantee: | Elexa Consumer Products, Inc. |
| Equipment Class: | Digital Transmission System |
| Notes: | Dome Hub |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15C | 2412.0 - 2462.0 | 0.417 |
| Power listed is the maximum conducted output power. Device is 2X2 MIMO. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi- transmitter product procedures. End-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. Device contains 20 and 40 MHz signal bandwidth. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Bureau Veritas Consumer Products Services, Inc. 775 Montague Expressway Milpitas, CA 95035 |
Date of Grant: 07/04/2016 Application Dated: 07/04/2016 |
| Elexa Consumer Products, Inc. |
| 2275 HALF DAY RD STE 160 |
| STE 160 |
| Bannockburn, IL 60015 |
| Attention: Shristi Sahu , Project Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | VII-DMGW1 |
| Name of Grantee: | Elexa Consumer Products, Inc. |
| Equipment Class: | Part 15 Low Power Communication Device Transmitter |
| Notes: | Dome Hub |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 908.4 - 916.0 |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
EAS Grant - Application s6kFBhU5jQJ7wTOBZSxQtw==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Elexa Consumer Products, Inc. 2275 HALF DAY RD STE 160 STE 160 Bannockburn, IL 60015 United States |
Date of Grant: 07/04/2016 Application Dated: 07/04/2016 |
| Attention: Shristi Sahu , Project Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | VII-DMGW1 |
| Name of Grantee: | Elexa Consumer Products, Inc. |
| Equipment Class: | Part 15 Low Power Communication Device Transmitter |
| Notes: | Dome Hub |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 908.4 - 916.0 |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| Mail To: |
