FCC ID VK6-ODU600LB
Eclipse ODU600
by Aviat Networks (S) Pte. Ltd
Grantee Code: VK6 Product Code: ODU600LB
Latest application date: 2016-06-02
Device Images
FCC ID Device Details
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 5728-5763 MHz | Original Equipment | 2016-06-02 |
| 5728-5763 MHz | Class II permissive change or modification of presently authorized equipment | 2016-01-15 |
| 5728-5763 MHz | Class II permissive change or modification of presently authorized equipment | 2014-05-22 |
| 5728-5763 MHz | Original Equipment | 2013-09-13 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2016-06-02 | PDF 2.5 MB |
| Installation Manual | Users Manual | 2013-09-13 | PDF 2.5 MB |
| Internal Photos | Internal Photos | 2016-06-02 | PDF 1.7 MB |
| External Photos | External Photos | 2016-06-02 | PDF 2.8 MB |
| Label Detail | ID Label/Location Info | 2016-06-02 | PDF 25.8 KB |
| Label Location | ID Label/Location Info | 2016-06-02 | PDF 377.2 KB |
| Label Drawing | ID Label/Location Info | 2013-09-13 | PDF 25.8 KB |
| Test Set Up | Test Setup Photos | 2016-06-02 | PDF 4.8 MB |
| Test Set Up | Test Setup Photos | 2016-01-15 | PDF 2.7 MB |
| Test Setup Photos | Test Setup Photos | 2013-09-13 | PDF 4.8 MB |
| Test Report 1 | Test Report | 2016-06-02 | PDF 464.2 KB |
| Test Report 2 | Test Report | 2016-06-02 | PDF 1.8 MB |
| Test Report 3 | Test Report | 2016-06-02 | PDF 1.3 MB |
| Test Report | Test Report | 2016-01-15 | PDF 1.3 MB |
| Test Report | Test Report | 2014-05-22 | PDF 464.2 KB |
| TCB Q&A | Test Report | 2013-09-13 | PDF 17.2 KB |
| Test Report | Test Report | 2013-09-13 | PDF 1.8 MB |
| Emissions Compliance Attestation | Attestation Statements | 2016-06-02 | PDF 390.5 KB |
| Antennas 1 | Cover Letter(s) | 2016-06-02 | PDF 15.7 KB |
| Antennas 2 | Cover Letter(s) | 2016-06-02 | PDF 19.7 KB |
| Application Letter | Cover Letter(s) | 2016-06-02 | PDF 472.2 KB |
| Authorisation Request | Cover Letter(s) | 2016-06-02 | PDF 157.4 KB |
| Confidentiality Request | Cover Letter(s) | 2016-06-02 | PDF 388.8 KB |
| TCB Address Change | Cover Letter(s) | 2016-06-02 | PDF 11.2 KB |
| TCB MPE Cover Letter | Cover Letter(s) | 2016-06-02 | PDF 47.5 KB |
| Authorisation Letter | Cover Letter(s) | 2016-01-15 | PDF 510.7 KB |
| Permissive Change Request | Cover Letter(s) | 2016-01-15 | PDF 884.1 KB |
| C2PC Request Letter | Cover Letter(s) | 2014-05-22 | PDF 69.2 KB |
| Cover Letter Power | Cover Letter(s) | 2014-05-22 | PDF 68.8 KB |
| Cover Letter TCB Q and A | Cover Letter(s) | 2014-05-22 | PDF 52.2 KB |
| Request for Confidentiality | Cover Letter(s) | 2013-09-13 | PDF 77 KB |
| MPE Calculation | RF Exposure Info | 2016-06-02 | PDF 80.6 KB |
| Block Diagram Metadata only | Block Diagram | PDF 67.1 KB | |
| Schematics Metadata only | Schematics | PDF 3.7 MB | |
| Operational Description Metadata only | Operational Description | PDF 36.6 KB | |
| Software Security Metadata only | SDR Software/Security Inf | PDF 39.9 KB | |
| BOM Metadata only | Parts List/Tune Up Info | PDF 86.4 KB |
Application Information
| Application ID | YqaDGMsrK7uO0dkV4Jdqjg== |
|---|---|
| Final Action Date | 2016-06-02 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0005089842 |
| Model | ODU600LB |
| Frequency Range | 5728-5763 MHz |
| Equipment Class | NII - Unlicensed National Information Infrastructure TX |
| Device Description | Eclipse ODU600 |
| Responsible Party | Ruth French, Product Compliance Manager, ruth.french@aviatnet.com  , 011447771978599 |
| Technical Contact | Ruth French, Aviat Networks, ruth.french@aviatnet.com , 44 1698 717200 |
| Non-Technical Contact | Ruth French, Aviat Networks, ruth.french@aviatnet.com , 44 1698 717200 |
| Test Firm | Darren Rust, UL VS Ltd, darren.rust@ul.com  , +44 1256 31 2119 |
| TCB Email | certification@ul.com |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power Output listed is conducted average. The antenna used for this transmitter must be installed to provide a separation distance of at least 1800 cm from all persons and must not be co-located with any other transmitters except in accordance with FCC multi-transmitter product procedures. For professional Installation. End users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has 5 MHz, 10 MHz, 20 MHz, 30 MHz and 40MHz bandwidth modes. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| YqaDGMsrK7uO0dkV4Jdqjg== | 2016-06-02 | Original Equipment |
| erDkX56TpeRfAwgnlkQwZg== | 2016-01-15 | Class II permissive change or modification of presently authorized equipment |
| ar8Z7/f2VRiaqYGCQagCWQ== | 2014-05-22 | Class II permissive change or modification of presently authorized equipment |
| u1flv2LE11ngjT9djvDuYA== | 2013-09-13 | Original Equipment |
Equipment Authorization
Grants
TCB Grant - Application YqaDGMsrK7uO0dkV4Jdqjg==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
UL International (UK) Ltd Unit 1 - 3 Horizon Kingsland Business Park Wade Road Basingstoke, RG24 8AH United Kingdom |
Date of Grant: 06/02/2016 Application Dated: 06/02/2016 |
| Aviat Networks (S) Pte. Ltd |
| 17 Changi Business Park Central 1 |
| 04-01 Honeywell Building |
| Singapore, 486073 Singapore |
| Attention: Ruth French , Product Compliance Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | VK6-ODU600LB |
| Name of Grantee: | Aviat Networks (S) Pte. Ltd |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Eclipse ODU600 |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 48 CC | 15E | 5728.0 - 5763.0 | 0.56 |
| Power Output listed is conducted average. The antenna used for this transmitter must be installed to provide a separation distance of at least 1800 cm from all persons and must not be co-located with any other transmitters except in accordance with FCC multi-transmitter product procedures. For professional Installation. End users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has 5 MHz, 10 MHz, 20 MHz, 30 MHz and 40MHz bandwidth modes. |
| 48: | The device has been approved under § 15.407(b)(4)(ii) for antenna gains greater than 10 dBi and cannot be manufactured, marketed, sold or imported after March 2, 2018. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
