FCC ID VKF-MWM1
MWM1
by Masimo Corporation
Grantee Code: VKF Product Code: MWM1
Latest application date: 2016-05-25
Device Images
FCC ID Device Details
| FCC ID | VKF-MWM1 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | VKF |
| Product Code | MWM1 |
| Applicant Business | Masimo Corporation 🇺🇸 |
| Related Domains |  masimo.com |
| Equipment Class | MWM1 |
| Test Firm | Northwest EMC, Inc. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2412-2462 MHz | Original Equipment | 2016-05-25 |
| 5180-5240 MHz | Original Equipment | 2016-05-25 |
| 2402-2480 MHz | Original Equipment | 2016-05-25 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| user manual | Users Manual | 2016-05-25 | PDF 200.5 KB |
| Internal Photos | Internal Photos | 2016-05-25 | PDF 507.3 KB |
| External Photos | External Photos | 2016-05-25 | PDF 371.8 KB |
| ID Label | ID Label/Location Info | 2016-05-25 | PDF 374.9 KB |
| Antenna info | Operational Description | 2016-05-25 | PDF 378.2 KB |
| Test Setup Photos | Test Setup Photos | 2016-05-25 | PDF 792.4 KB |
| Test Setup Photos | Test Setup Photos | 2016-05-25 | PDF 931.3 KB |
| Test setup photos | Test Setup Photos | 2016-05-25 | PDF 1.1 MB |
| Test REport | Test Report | 2016-05-25 | PDF 1.7 MB |
| Test Report | Test Report | 2016-05-25 | PDF 2.9 MB |
| Test Report | RF Exposure Info | 2016-05-25 | PDF 71.3 KB |
| Cover letter | Cover Letter(s) | 2016-05-25 | PDF 15.5 KB |
| Modular approval letter | Cover Letter(s) | 2016-05-25 | PDF 21 KB |
| Request for confidentiality | Cover Letter(s) | 2016-05-25 | PDF 21.3 KB |
| Report | RF Exposure Info | 2016-05-25 | PDF 71.3 KB |
| SAR report | RF Exposure Info | 2016-05-25 | PDF 2.1 MB |
| Frequency Block Diagram Metadata only | Block Diagram | PDF 174.6 KB | |
| Schematics Metadata only | Schematics | PDF 36.2 KB | |
| Operational Description Metadata only | Operational Description | PDF 35.1 KB | |
| Software Security Metadata only | Operational Description | PDF 102.5 KB | |
| Software Security updated Metadata only | Operational Description | PDF 103.9 KB |
Application Information
| Application ID | z/0+W8CTim5xFZ5pkhs+eQ== |
|---|---|
| Final Action Date | 2016-05-25 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0016800161 |
| Model | MWM1 |
| Frequency Range | 2412-2462 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | MWM1 |
| Responsible Party | Anamidevi Joshi, EMC Manager, ajoshi@masimo.com , 949-297-7663 |
| Test Firm | Greg Kiemel, Northwest EMC, Inc., gkiemel@nwemc.com  , 503-844-4066 |
| TCB Email | gkiemel@nwemc.com |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Limited Single Modular Approval |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power output listed is conducted. This device must transmit with a source-based time-averaging duty factor not exceeding 6%. Approval is limited to installation by the grantee in a portable host (Masimo, RAD7A) as documented in this filing. The antenna(s) used for this transmitter must not be co-located with any other transmitters except in accordance with FCC multi-transmitter product procedures. SAR compliance for body-worn operating conditions is limited to the specific configurations tested for this filing. End users must be informed of the body worn requirements for satisfying RF Exposure compliance. The highest reported SAR values are: Body-worn: < 0.10 W/kg |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| z/0+W8CTim5xFZ5pkhs+eQ== | 2016-05-25 | Original Equipment |
| nBl5JMP/e9oIQEy8Uf641g== | 2016-05-25 | Original Equipment |
| 6ymWPbU+xzSW0FOHohYrnw== | 2016-05-25 | Original Equipment |
Equipment Authorization
Grants
TCB Grant - Application z/0+W8CTim5xFZ5pkhs+eQ==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Element Materials Technology Portland - Evergreen 6775 NE Evergreen Parkway, Suite 400 Hillsboro, OR 97124 |
Date of Grant: 05/25/2016 Application Dated: 05/25/2016 |
| Masimo Corporation |
| 52 Discovery |
| Irvine, CA 92618 |
| Attention: Anamidevi Joshi , EMC Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | VKF-MWM1 |
| Name of Grantee: | Masimo Corporation |
| Equipment Class: | Digital Transmission System |
| Notes: | MWM1 |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2412.0 - 2462.0 | 0.0539 |
| Power output listed is conducted. This device must transmit with a source-based time-averaging duty factor not exceeding 6%. Approval is limited to installation by the grantee in a portable host (Masimo, RAD7A) as documented in this filing. The antenna(s) used for this transmitter must not be co-located with any other transmitters except in accordance with FCC multi-transmitter product procedures. SAR compliance for body-worn operating conditions is limited to the specific configurations tested for this filing. End users must be informed of the body worn requirements for satisfying RF Exposure compliance. The highest reported SAR values are: Body-worn: < 0.10 W/kg |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
