A6 BLUETOOTH HEADSET (CLASS 2) Schematics - FCC ID VO8A6

FCC ID VO8A6

SCHEMATICS

BLUETOOTH HEADSET (CLASS 2)

by GuangZhou LIWEI Electronics, LTD

Document preview loads when visible.

Document Details

FCC IDVO8A6
Document ID922948
Document TypeSchematics
DescriptionSCHEMATICS
Document TitleProtel Schematic
ApplicantGuangZhou LIWEI Electronics, LTD
Equipment ClassBLUETOOTH HEADSET (CLASS 2)
Product CodeA6
Application IDdTg3N11L+FMyLmnoCMOF6A==
Application PurposeOriginal Equipment
Application Date2008-04-02
Frequency Range2402-2480 MHz
FRN0016950743
Test FirmWorld Standardization Certification&Testing; CO.,LT
Certified ByBO YAO GENERAL ENGINEER
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2008-04-02
Available2008-04-02
Created2008-03-21
Modified2008-04-02
Pages1
File TypeAdobe Acrobat PDF
File Size37342
File SHA-2569f2800c2ea23f7416b9f63b1e8d4e13672be9871618b07a668eeb8ed33855770
PDF Metadata AuthorAdministrator
PDF Metadata CreatorpdfFactory Pro www.fineprint.com.cn
PDF Metadata ProducerpdfFactory Pro 2.10 (Windows XP Chinese)
FCC.gov SourcesFCC.gov 922948
