FCC ID VRSGW52
MOD-SM QIS BT/WLAN CWM-02B-BT2-SP D5
by Qisda Corporation
Grantee Code: VRS Product Code: GW52
Latest application date: 2016-06-14
Device Images
FCC ID Device Details
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2402-2480 MHz | Original Equipment | 2016-06-14 |
| 2412-2462 MHz | Original Equipment | 2016-06-14 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2016-06-14 | PDF 1.1 MB |
| Internal Photos | Internal Photos | 2016-06-14 | PDF 169.2 KB |
| External Photos | External Photos | 2016-06-14 | PDF 158.4 KB |
| ID Label | ID Label/Location Info | 2016-06-14 | PDF 61.2 KB |
| Block Diagrams | Block Diagram | 2016-06-14 | PDF 216.4 KB |
| Schematics_1 | Schematics | 2016-06-14 | PDF 52.6 KB |
| Schematics_2 | Schematics | 2016-06-14 | PDF 131.2 KB |
| Antenna Spec | Operational Description | 2016-06-14 | PDF 488.7 KB |
| Operational Description | Operational Description | 2016-06-14 | PDF 171.5 KB |
| Test Setup Photos | Test Setup Photos | 2016-06-14 | PDF 409.1 KB |
| Test Report_BT | Test Report | 2016-06-14 | PDF 2 MB |
| Test Report_WLAN | Test Report | 2016-06-14 | PDF 5 MB |
| Auth. Letter | Cover Letter(s) | 2016-06-14 | PDF 120.9 KB |
| Modular approval letter | Cover Letter(s) | 2016-06-14 | PDF 367.7 KB |
| MPE | RF Exposure Info | 2016-06-14 | PDF 32 KB |
Application Information
| Application ID | zBJTs2mBx7xSh6WZ9A9YTg== |
|---|---|
| Final Action Date | 2016-06-14 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0016869570 |
| Model | GW52 |
| Frequency Range | 2402-2480 MHz |
| Equipment Class | DSS - Part 15 Spread Spectrum Transmitter |
| Device Description | MOD-SM QIS BT/WLAN CWM-02B-BT2-SP D5 |
| Responsible Party | Tom CK Lung, Researcher, Tom.CK.Lung@Qisda.com  , +886-359-8800 |
| Test Firm | Winpo Tsai, Electronics Testing Center, Taiwan, winpo@etc.org.tw  , 886-3-3280026 |
| TCB Email | LST.FRE.CertNotice@ul.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Modular approval. Output power listed is conducted. This module may only be installed by the OEM or an OEM integrator. Only antenna(s) documented in this filings may be used with this transmitter. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures. OEM integrators, end-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
