09101 Employee Time Clock Test Setup Photos - FCC ID VRW09101

FCC ID VRW09101

Test Setup Photos

Employee Time Clock

by ICON Time Systems

Document preview loads when visible.

Document Details

FCC IDVRW09101
Document ID984625
Document TypeTest Setup Photos
DescriptionTest Setup Photos
Document Title3
ApplicantICON Time Systems
Equipment ClassEmployee Time Clock
Product Code09101
Application IDtlmskLGSI/97MCNPt+QxuQ==
Application PurposeOriginal Equipment
Application Date2008-08-13
Frequency Range0.125 MHz
FRN0017055542
Test FirmTimco Engineering, Inc.
Certified ByScott Maclean
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2008-08-13
Available2008-08-13
Created2008-08-06
Modified2008-08-06
Pages3
File TypeAdobe Acrobat PDF
File Size163713
File SHA-256d5ddbed64e1c5a29d0b9a7645f99a002c5f5dc71ce4ee68949c9b20ad3fb94ce
PDF Metadata AuthorRita
PDF Metadata CreatorPScript5.dll Version 5.2
PDF Metadata ProducerAcrobat Distiller 6.0 (Windows)
FCC.gov SourcesFCC.gov 984625
