CGM4231 DOCSIS3.1 Wireless Residential... - FCC ID VUICGM4231

FCC ID VUICGM4231

Test Setup Photos

DOCSIS3.1 Wireless Residential Gateway with Embedded Digital Voice Adapter

by PEGATRON CORPORATION

Document preview loads when visible.

Document Details

FCC IDVUICGM4231
Document ID3670979
Document TypeTest Setup Photos
DescriptionTest Setup Photos
Document Title1
ApplicantPEGATRON CORPORATION
Equipment ClassDOCSIS3.1 Wireless Residential Gateway with Embedded Digital Voice Adapter
Product CodeCGM4231
Application IDMR1/GzJpHqRXtbgN+sAiFA==
Application PurposeClass II Permissive Change
Application Date2018-03-19
Frequency Range5180-5240 MHz
FRN0020241758
Test FirmBureau Veritas CPS (H.K.) Ltd., Taoyuan Branch
Certified ByMiffy Tsao Specialist
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date09/15/2018
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2017-12-11
Available2018-09-15
Created2017-05-16
Modified2017-05-16
Pages3
File TypeAdobe Acrobat PDF
File Size324301
File SHA-256b235199f1c6d0bba28e371ffd1eb1af27c3e0b5a706fe2d90c74f5c5a7cdfd03
PDF Metadata AuthorJim
PDF Metadata ProducerJim Microsoft® Office Word 2007
FCC.gov SourcesFCC.gov 3670979, FCC.gov 3403524
