MD100 Module Test Setup Photos - FCC ID VUIMD100

FCC ID VUIMD100

TSUP Part 27Q

Module

by PEGATRON CORPORATION

Document preview loads when visible.

Document Details

FCC IDVUIMD100
Document ID6561254
Document TypeTest Setup Photos
DescriptionTSUP Part 27Q
ApplicantPEGATRON CORPORATION
Equipment ClassModule
Product CodeMD100
Application ID3+xVYuWzBfoQk3ScdbPqug==
Application PurposeClass II Permissive Change
Application Date2023-06-21
Frequency Range1702.5 MHz
FRN0020241758
Test FirmSporton International Inc.
Certified ByLeo Huang VP
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date12/18/2023
Grant DeferralNo
Modular EquipmentSingle Modular Approval
Composite DeviceYes
Composite PartNo
Submitted2023-05-30
Available2023-12-18
Created2023-05-25
Modified2023-05-25
Pages2
File TypeAdobe Acrobat PDF
File Size302816
File SHA-25668d2ee73f2f9d9f259312a2013bb77a5a20c99be101b5c6ebdf43a46400490c7
PDF Metadata ProducerMicrosoft® Word 2010 Microsoft® Word 2010
FCC.gov SourcesFCC.gov 6561254
