FCC ID VW4A092722
ATSAMR30-XPRO
by Microchip Technology Inc.
Grantee Code: VW4 Product Code: A092722
Latest application date: 2017-03-27
Device Images
FCC ID Device Details
| FCC ID | VW4A092722 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | VW4 |
| Product Code | A092722 |
| Applicant Business | Microchip Technology Inc. 🇺🇸 |
| Related Domains |  microchip.com |
| Equipment Class | ATSAMR30-XPRO |
| Test Firm | Bay Area Compliance Laboratories Corp.(kunshan) |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 906-924 MHz | Original Equipment | 2017-03-27 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Users Manual | Users Manual | 2017-03-27 | PDF 2.6 MB |
| Int Photos | Internal Photos | 2017-03-27 | PDF 119.3 KB |
| Ext Photos | External Photos | 2017-03-27 | PDF 94.2 KB |
| FCC ID Label | ID Label/Location Info | 2017-03-27 | PDF 52.1 KB |
| Setup Photos | Test Setup Photos | 2017-03-27 | PDF 206.6 KB |
| Test Report | Test Report | 2017-03-27 | PDF 969.5 KB |
| Attestation Letter | Attestation Statements | 2017-03-27 | PDF 58.1 KB |
| Confidentiality Letter | Cover Letter(s) | 2017-03-27 | PDF 18.4 KB |
| LMA Letter | Cover Letter(s) | 2017-03-27 | PDF 14.9 KB |
| POA | Cover Letter(s) | 2017-03-27 | PDF 14 KB |
| Block Diagram Metadata only | Block Diagram | PDF 17.7 KB | |
| Schematics Metadata only | Schematics | PDF 464.8 KB | |
| Operation Description Metadata only | Operational Description | PDF 243.5 KB |
Application Information
| Application ID | Pz8Bkix6UEOCKwB/r41KCw== |
|---|---|
| Final Action Date | 2017-03-27 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0018576819 |
| Model | A092722 |
| Frequency Range | 906-924 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | ATSAMR30-XPRO |
| Responsible Party | Steve Caldwell, Vice President, Wireless Solutions Group, steve.caldwell@microchip.com , +1 480 792 7464 |
| Test Firm | john chan, Bay Area Compliance Laboratories Corp.(kunshan), john.chan@baclcorp.com  , 86051286175000 |
| TCB Email | bacl.regulatory@baclcorp.com |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Limited Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Limited modular approval. Output power listed is conducted. This module is approved for use only in the mobile configurations associated with this filing. This grant is valid only when the module is sold to OEM integrators and must be installed by the OEM or OEM integrators. Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users may not be provided with the module installation instructions. Compliance of this device in all final host configurations is the responsibility of the Grantee. |
