AT2009 WIRELESS TRANSMITTER Teardown Internal... - FCC ID VZ5AT2009

FCC ID VZ5AT2009

INTERNAL PHOTOS

WIRELESS TRANSMITTER

by GUANG ZHOU AUTORAIL CO., LTD.

Document preview loads when visible.

Document Details

FCC IDVZ5AT2009
Document ID908231
Document TypeInternal Photos
DescriptionINTERNAL PHOTOS
Document Titleuntitled
ApplicantGUANG ZHOU AUTORAIL CO., LTD.
Equipment ClassWIRELESS TRANSMITTER
Product CodeAT2009
Application IDfLIOenUk1FfaRiIPv+GUVQ==
Application PurposeOriginal Equipment
Application Date2008-02-29
Frequency Range433.87 MHz
FRN0017370743
Test FirmWorld Standardization Certification&Testing; CO.,LT
Certified ByZHIBIN YIN GENERAL MANAGER
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2008-02-29
Available2008-02-29
Created2008-01-28
Modified2008-01-28
Pages1
File TypeAdobe Acrobat PDF
File Size69417
File SHA-2564e35e89c644577532583ebd2d61dff78c44612ff2e9b6c84d4b6a8b03b9e4d3a
PDF Metadata AuthorNone
PDF Metadata CreatorNone
PDF Metadata ProducerAcrobat Distiller 7.0 (Windows)
FCC.gov SourcesFCC.gov 908231
