FCC ID W7Z-WB4343WF3SP2
WiFi/Bluetooth/Bluetooth Smart Mini Module
by California Eastern Laboratories
Grantee Code: W7Z Product Code: WB4343WF3SP2
Latest application date: 2016-07-27
Device Images
FCC ID Device Details
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2402-2480 MHz | Original Equipment | 2016-07-27 |
| 2402-2480 MHz | Original Equipment | 2016-07-27 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Exhibit D Users Manual per 2 1033 b3 | Users Manual | 2016-07-27 | PDF 531.1 KB |
| Exhibit C Internal Photographs per 2 1033 b7 | Internal Photos | 2016-07-27 | PDF 72.1 KB |
| Exhibit C External Photographs per 2 1033 b7 | External Photos | 2016-07-27 | PDF 72.1 KB |
| Exhibit A ID Label and location per 2 1033 b7 | ID Label/Location Info | 2016-07-27 | PDF 122.4 KB |
| Exhibit B Block Diagram per 2 1033 b5 | Block Diagram | 2016-07-27 | PDF 83.5 KB |
| Exhibit B Operational Description per 2 1033 b4 | Operational Description | 2016-07-27 | PDF 531.1 KB |
| Exhibit C RE Test Setup photographs | Test Setup Photos | 2016-07-27 | PDF 192 KB |
| Exhibit E Test Measurement Report per 2 1033 b6 | Test Report | 2016-07-27 | PDF 4.9 MB |
| Exhibit E Test Measurement Report per 2 1033 c14 | Test Report | 2016-07-27 | PDF 1.9 MB |
| Cover Letter Requesting Confidentiality | Cover Letter(s) | 2016-07-27 | PDF 41.7 KB |
| Cover Letter Requesting Modular Approval | Cover Letter(s) | 2016-07-27 | PDF 40.9 KB |
| Exhibit B Schematics per 2 1033 b5 Metadata only | Schematics | PDF 184.4 KB | |
| Misc Parts List Exhibits Metadata only | Parts List/Tune Up Info | PDF 100 KB |
Application Information
| Application ID | f/L1pjnyGvPQvYAPEVrdJw== |
|---|---|
| Final Action Date | 2016-07-27 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0007032923 |
| Model | WB4343WF3SP2 |
| Frequency Range | 2402-2480 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | WiFi/Bluetooth/Bluetooth Smart Mini Module |
| Responsible Party | David Wilde, david.wilde@cel.com  , 4089192500 |
| Technical Contact | Benjamin White, California Eastern Laboratories, benjamin.white@cel.com , 8478588803 |
| Test Firm | Kevin Halpin, Elite Electronic Engineering Inc., khalpin@elitetest.com  , 630-495-9770 |
| TCB Email | decrowder@elitetest.com |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power listed is conducted. The antenna(s) used for this transmitter must not transmit simultaneously with any other antenna or transmitter, except in accordance with FCC multi-transmitter product procedures. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. Approved for used with antenna(s) as listed in this filing. |
