F9B FM Transmitter Schematics - FCC ID W8D-F9B

FCC ID W8D-F9B

Schematics

FM Transmitter

by Shenzhen Onuoda Electronics Technology Co.Ltd

Document preview loads when visible.

Document Details

FCC IDW8D-F9B
Document ID1169080
Document TypeSchematics
DescriptionSchematics
Document TitleProtel Schematic
ApplicantShenzhen Onuoda Electronics Technology Co.Ltd
Equipment ClassFM Transmitter
Product CodeF9B
Application IDgjMQqDuZSoNnWl7L+TXNdQ==
Application PurposeOriginal Equipment
Application Date2009-09-14
Frequency Range88.1-107.9 MHz
FRN0018601344
Test FirmShenzhen Certification Technology Service Co.,Ltd
Certified ByAndy Guo
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2009-09-14
Available2009-09-14
Created2009-05-09
Modified2009-09-14
Pages1
File TypeAdobe Acrobat PDF
File Size26686
File SHA-25695f38840add668338b7be704b1ded20c12c4f7ee6f83ae005dffa99a71fa67ec
PDF Metadata AuthorAdministrator
PDF Metadata CreatorpdfFactory Pro www.fineprint.cn
PDF Metadata ProducerpdfFactory Pro 3.21 (Windows XP Professional Chinese)
FCC.gov SourcesFCC.gov 1169080
