SFTS500 500mW Radio Module Label Diagram - FCC ID W8V-SFTS500
FCC ID W8V-SFTS500
Label
500mW Radio Module
Document preview loads when visible.
Document Details
| FCC ID | W8V-SFTS500 |
|---|---|
| Document ID | 3767873 |
| Document Type | ID Label/Location Info |
| Description | Label |
| Applicant | SignalFire Telemetry, Inc. |
| Equipment Class | 500mW Radio Module |
| Product Code | SFTS500 |
| Application ID | pg1lUjq2uTfDquN/njc/Pw== |
| Application Purpose | Original Equipment |
| Application Date | 2018-03-02 |
| Frequency Range | 905-925 MHz |
| FRN | 0018614347 |
| Test Firm | BUREAU VERITAS CONSUMER PRODUCTS SERVICES, INC. |
| Certified By | Yunus Faziloglu Sr. EMC Engineer |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2018-03-02 |
| Available | 2018-03-02 |
| Created | 2018-01-09 |
| Modified | 2018-01-09 |
| Pages | 1 |
| File Type | Adobe Acrobat PDF |
| File Size | 217546 |
| File SHA-256 | ec268d916bcba1c05f40f804ac2e4cf4680e36f860d48e008dc93d2246533fa2 |
| PDF Metadata Author | Scott Keller |
| PDF Metadata Producer | Microsoft® Visio® 2016 Scott Keller |
| FCC.gov Sources | FCC.gov 3767873 |
