R27 Mobile Phone Teardown Internal Photos - FCC ID WA6R27

FCC ID WA6R27

Internal Photos

Mobile Phone

by VeryKool USA Inc

Document preview loads when visible.

Document Details

FCC IDWA6R27
Document ID2243918
Document TypeInternal Photos
DescriptionInternal Photos
Document Title13070616-FCC-E-15B
ApplicantVeryKool USA Inc
Equipment ClassMobile Phone
Product CodeR27
Application ID09KKr1Sus9wf5BvhfI+A6w==
Application PurposeOriginal Equipment
Application Date2014-04-16
Frequency Range1850.2-1909.8 MHz
FRN0017760091
Test FirmSIEMIC (Shenzhen-China) Laboratories
Certified BySunny Choi
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2014-04-16
Available2014-04-16
Created2014-04-01
Modified2014-04-01
Pages7
File TypeAdobe Acrobat PDF
File Size1419604
File SHA-256be2f91d6bb8a0e8a73920406d7c9778ee23a1b8ca8ded21c2d47fdd9eeabbdf5
PDF Metadata AuthorAdministrator
PDF Metadata ProducerAdministrator Acrobat Distiller 10.0.0 (Windows)
FCC.gov SourcesFCC.gov 2243918, FCC.gov 2243893, FCC.gov 2243864
