BTH033L Bluetooth Stereo Headset Teardown... - FCC ID WAD-BTH033L

FCC ID WAD-BTH033L

Internal Photos

Bluetooth Stereo Headset

by Zhongshan K-mate General Electronics Co., Ltd

Document preview loads when visible.

Document Details

FCC IDWAD-BTH033L
Document ID2693626
Document TypeInternal Photos
DescriptionInternal Photos
Document Titleuntitled
ApplicantZhongshan K-mate General Electronics Co., Ltd
Equipment ClassBluetooth Stereo Headset
Product CodeBTH033L
Application IDGvXzr/yEsvDvTVp+6n1A8g==
Application PurposeOriginal Equipment
Application Date2015-07-27
Frequency Range2402-2480 MHz
FRN0017689183
Test FirmBay Area Compliance Laboratories Corp. (Dongguan)
Certified ByDecai Liu
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2015-07-27
Available2015-07-27
Created2015-07-25
Modified2015-07-25
Pages4
File TypeAdobe Acrobat PDF
File Size239246
File SHA-256dcd9f04ee0f7959adcc6cb46aa92a5ccea1dc7ee0d7440e73abf5ff2f5867c37
PDF Metadata ProducerAcrobat Distiller 7.0 (Windows)
FCC.gov SourcesFCC.gov 2693626, FCC.gov 2693616
