FCC ID WAP3136
Modules CYBLE-413136-01,CYBLE-473142-01,CYBLE-413149-01,CYBLE-473148-01 Bluetooth wireless EZ-BLE Module with HomeKit
by Cypress Semiconductor
Grantee Code: WAP Product Code: 3136
Latest application date: 2018-05-16
Device Images
FCC ID Device Details
| FCC ID | WAP3136 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | WAP |
| Product Code | 3136 |
| Applicant Business | Cypress Semiconductor 🇺🇸 |
| Related Domains |  infineon.com |
| Equipment Class | Modules CYBLE-413136-01,CYBLE-473142-01,CYBLE-413149-01,CYBLE-473148-01 Bluetooth wireless EZ-BLE Module with HomeKit |
| Test Firm | DEKRA Testing and Certification (Suzhou) Co., Ltd. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2402-2480 MHz | Class II permissive change or modification of presently authorized equipment | 2018-05-16 |
| 2402-2480 MHz | Class II permissive change or modification of presently authorized equipment | 2018-05-08 |
| 2402-2480 MHz | Original Equipment | 2017-05-18 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual_CYBLE-413136-01 | Users Manual | 2018-05-16 | PDF 3.2 MB |
| User Manual_CYBLE-413149-01 | Users Manual | 2018-05-16 | PDF 1 MB |
| User manual_CYBLE-473142-01 | Users Manual | 2018-05-16 | PDF 1 MB |
| User manual_CYBLE-473148-01 | Users Manual | 2018-05-16 | PDF 1 MB |
| Use rmanual_CYBLE-473142-01 | Users Manual | 2018-05-08 | PDF 1 MB |
| Use rmanual_CYBLE-473148-01 | Users Manual | 2018-05-08 | PDF 1 MB |
| User Manual | Users Manual | 2017-11-14 | PDF 3.2 MB |
| Internal Photograph 0502 | Internal Photos | 2018-05-16 | PDF 462.4 KB |
| Internal Photographs | Internal Photos | 2017-11-14 | PDF 283.9 KB |
| External photographs | External Photos | 2017-11-14 | PDF 2.1 MB |
| Label Location | ID Label/Location Info | 2018-05-16 | PDF 1.8 MB |
| ID Label and Location | ID Label/Location Info | 2017-05-18 | PDF 289.4 KB |
| Block Diagram-0502 | Block Diagram | 2018-05-16 | PDF 1.7 MB |
| schematic_CYBLE-413136-01&CYBLE-473142-01 | Schematics | 2018-05-16 | PDF 158.4 KB |
| schematic_CYBLE-413149-01&CYBLE-473148-01 | Schematics | 2018-05-16 | PDF 157.4 KB |
| Change Description - 0502 | Operational Description | 2018-05-16 | PDF 4.4 MB |
| Difference Description_updated_V0.1 | Operational Description | 2018-05-16 | PDF 4.4 MB |
| CYBLE-413136-01, CYBLE-473142-01, CYBLE-413149-01 and CYBLE-473148-01 Differenc | Operational Description | 2018-05-08 | PDF 4.4 MB |
| FCC-Test Setup Photographs | Test Setup Photos | 2018-05-16 | PDF 280.2 KB |
| SAR Test report Calibration data | Test Setup Photos | 2017-11-14 | PDF 280.2 KB |
| 1832181R-FCC statement for SAR not required-EZ-BLE Module with HomeKit-CYBLE-413 | Test Report | 2018-05-08 | PDF 154.6 KB |
| 1832181R-IC statement for SAR not required-EZ-BLE Module with HomeKit-CYBLE-4131 | Test Report | 2018-05-08 | PDF 159 KB |
| 1832181R-RF-FCC-FCC Part15.247(BT 4.2)-EZ-BLE Module with HomeKit-CYBLE-413136-0 | Test Report | 2018-05-08 | PDF 992.7 KB |
| Test report | Test Report | 2017-05-18 | PDF 1 MB |
| Authorization letter | Cover Letter(s) | 2018-05-16 | PDF 49.8 KB |
| WAP3136_FCB011_02 FCC Agent letter | Cover Letter(s) | 2018-05-16 | PDF 145.4 KB |
| WAP3136_FCB012_02 FCC Confidentiality Request | Cover Letter(s) | 2018-05-16 | PDF 253.3 KB |
| Authorization letter_WAP3136_7922A-3136 | Cover Letter(s) | 2018-05-08 | PDF 49.8 KB |
| Authorization letter | Cover Letter(s) | 2017-05-18 | PDF 25 KB |
| Confidentiality Request Letter | Cover Letter(s) | 2017-05-18 | PDF 245.8 KB |
| FCC Agent Letter | Cover Letter(s) | 2017-05-18 | PDF 186.3 KB |
| Modular Approval Letter | Cover Letter(s) | 2017-05-18 | PDF 123.4 KB |
| Sar Not Required | RF Exposure Info | 2017-05-18 | PDF 116.2 KB |
| Block Diagram Metadata only | Block Diagram | PDF 189.8 KB | |
| Schematics Metadata only | Schematics | PDF 154.4 KB | |
| Description of device Metadata only | Operational Description | PDF 78.4 KB |
Application Information
| Application ID | sPrNzhitS18XtatHlCmzjg== |
|---|---|
| Final Action Date | 2018-05-16 |
| Application Purpose | Class II permissive change or modification of presently authorized equipment |
| Applicant FRN | 0017759150 |
| Model | 3136 |
| Frequency Range | 2402-2480 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | Modules CYBLE-413136-01,CYBLE-473142-01,CYBLE-413149-01,CYBLE-473148-01 Bluetooth wireless EZ-BLE Module with HomeKit |
| Responsible Party | Kalyan Dharanipragada, Kal.Dharanipragada@infineon.com , 408-468-3617 |
| Test Firm | Janet Xu, DEKRA Testing and Certification (Suzhou) Co., Ltd., janet.xu@dekra.com  , 86 512 6251 50885113 |
| TCB Email | admin.rcb.es@dekra.com |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Modular Approval. Output power is conducted. This device meets the SAR Test Exclusion threshold specified in KDB447498 and is authorized for portable and mobile operation. Colocation with other transmitters would require the use of FCC multitransmitter product procedures. Installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying EMC and RF exposure compliance. The Grantee is responsible for providing the documentation required for modular use. The responsibility for the use of this module, in all configurations used or contemplated, remains with the Grantee. |
