1516 Retractable Bluetooth Headset Block Diagram - FCC ID WD31516

FCC ID WD31516

Block Diagram

Retractable Bluetooth Headset

by Channel Enterprises (HK) Ltd.

Document preview loads when visible.

Document Details

FCC IDWD31516
Document ID1493865
Document TypeBlock Diagram
DescriptionBlock Diagram
ApplicantChannel Enterprises (HK) Ltd.
Equipment ClassRetractable Bluetooth Headset
Product Code1516
Application IDqsvz+asfxEDsaAf/yM99Vg==
Application PurposeOriginal Equipment
Application Date2011-07-01
Frequency Range2402-2480 MHz
FRN0017856600
Test FirmSinTek Laboratory Co., Ltd.
Certified ByMing Chan Director
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2011-07-01
Available2011-07-01
Created2011-06-10
Modified2011-06-10
Pages1
File TypeAdobe Acrobat PDF
File Size38824
File SHA-2562a6aa8d5473c7fb06a0dfff03d0d8566d0292eaa698bc8bb678ff39ab4e591d5
PDF Metadata ProducerFoxit PDF Creator Version 3.1.0.1210
FCC.gov SourcesFCC.gov 1493865
