RCF49 RC Bug Teardown Internal Photos - FCC ID WFTRCF49

FCC ID WFTRCF49

Internal Photos

RC Bug

by Lan-Tech International Limited

Document preview loads when visible.

Document Details

FCC IDWFTRCF49
Document ID961626
Document TypeInternal Photos
DescriptionInternal Photos
Document TitleNone
ApplicantLan-Tech International Limited
Equipment ClassRC Bug
Product CodeRCF49
Application ID7tYnFZbPdEf4WfTINYgw7A==
Application PurposeOriginal Equipment
Application Date2008-06-27
Frequency Range49.86 MHz
FRN0017893710
Test FirmAccurate Technology Co., Ltd.
Certified ByHenry Chan Main Land Branch Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2008-06-27
Available2008-06-27
Created2008-06-25
Modified2008-06-25
Pages4
File TypeAdobe Acrobat PDF
File Size2457229
File SHA-2569d35329324342214b6615dfa73ec7ea87404f657db3830fc2dd8baddea0189c7
PDF Metadata AuthorNone
PDF Metadata CreatorAdobe Acrobat 7.0
PDF Metadata ProducerAdobe Acrobat 7.0 Image Conversion Plug-in
FCC.gov SourcesFCC.gov 961626
