BTTC580 Avantree Orbit External Photos - FCC ID WJ5-BTTC-580

FCC ID WJ5-BTTC-580

External Photos

Avantree Orbit

by Avantronics Limited

Document preview loads when visible.

Document Details

FCC IDWJ5-BTTC-580
Document ID4995395
Document TypeExternal Photos
DescriptionExternal Photos
ApplicantAvantronics Limited
Equipment ClassAvantree Orbit
Product CodeBTTC580
Application ID6uluYRrNi1IaF//i4viOOg==
Application PurposeOriginal Equipment
Application Date2020-11-12
Frequency Range2402-2480 MHz
FRN0017985342
Test FirmShenzhen Huaxia Testing Technology Co., Ltd
Certified ByPhoebe Yi Product Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2020-11-12
Available2020-11-12
Created2020-11-11
Modified2020-11-11
Pages4
File TypeAdobe Acrobat PDF
File Size558361
File SHA-256244872a36b45b7d7cb4e12aecc2fcd03fe2c9a1a2c4cb69e88c4a952bbe1d40e
PDF Metadata Authorwin7
PDF Metadata ProducerMicrosoft® Word 2016 win7
FCC.gov SourcesFCC.gov 4995395
