TC12AW 12 Inch Multi Function Pad Test Report - FCC ID WL6TC12A-W

FCC ID WL6TC12A-W

Test Report (NII)-Part V

12 Inch Multi Function Pad

by ELITEGROUP COMPUTER SYSTEMS CO., LTD

Document preview loads when visible.

Document Details

FCC IDWL6TC12A-W
Document ID3139941
Document TypeTest Report
DescriptionTest Report (NII)-Part V
Document TitleC1M1605220-F160347 ECS mPAD-12-CHT4-I_160614__5G_-Appendix A
ApplicantELITEGROUP COMPUTER SYSTEMS CO., LTD
Equipment Class12 Inch Multi Function Pad
Product CodeTC12AW
Application IDcMIwx5wJxKlrAjJB8hwAJQ==
Application PurposeOriginal Equipment
Application Date2016-09-21
Frequency Range5180-5240 MHz
FRN0018032326
Test FirmAudix Technology Corporation
Certified ByBen Cheng
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2016-09-20
Available2016-09-21
Created2016-07-04
Modified2016-07-04
Pages20
File TypeAdobe Acrobat PDF
File Size3939759
File SHA-256b1be9f6ba95b842e52215ed89c6df5a6f19e91175b08e18aa10939ff2839e5df
PDF Metadata Authorannie_yu
PDF Metadata Producerannie_yu Acrobat Distiller 7.0.5 (Windows)
FCC.gov SourcesFCC.gov 3139941
