FCC ID WP5TWN4F3
RFID Reader
by Elatec GmbH
Grantee Code: WP5 Product Code: TWN4F3
Latest application date: 2017-03-17
Device Images
FCC ID Device Details
| FCC ID | WP5TWN4F3 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | WP5 |
| Product Code | TWN4F3 |
| Applicant Business | Elatec GmbH 🇩🇪 |
| Related Domains |  elatec.com |
| Equipment Class | RFID Reader |
| Test Firm | Element Material Technology Straubing GmbH |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 0.125 MHz | Original Equipment | 2017-03-17 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| user manual | Users Manual | 2017-03-17 | PDF 169.7 KB |
| Int photos | Internal Photos | 2017-03-17 | PDF 533.6 KB |
| ext photos | External Photos | 2017-03-17 | PDF 533.6 KB |
| label and location | ID Label/Location Info | 2017-03-17 | PDF 291.4 KB |
| Test Setup photos HF | Test Setup Photos | 2017-03-17 | PDF 1.1 MB |
| test setup photos LF | Test Setup Photos | 2017-03-17 | PDF 991.6 KB |
| Test Report | Test Report | 2017-03-17 | PDF 698.3 KB |
| test report | Test Report | 2017-03-17 | PDF 895.5 KB |
| Declaration BT module | Attestation Statements | 2017-03-17 | PDF 10.4 KB |
| LTC request | Cover Letter(s) | 2017-03-17 | PDF 336.7 KB |
| MA Letter | Cover Letter(s) | 2017-03-17 | PDF 607.5 KB |
| PoA | Cover Letter(s) | 2017-03-17 | PDF 299.5 KB |
| block diagram Metadata only | Block Diagram | PDF 205.6 KB | |
| schematics Metadata only | Schematics | PDF 602.3 KB | |
| operational description Metadata only | Operational Description | PDF 377.4 KB |
Application Information
| Application ID | 1ivGg6ZhN9ta1+nPEAPLAA== |
|---|---|
| Final Action Date | 2017-03-17 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0018113688 |
| Model | TWN4F3 |
| Frequency Range | 0.125 MHz |
| Equipment Class | DXX - Part 15 Low Power Communication Device Transmitter |
| Device Description | RFID Reader |
| Responsible Party | Birgit Bachl, b.bachl@elatec.com , +49895529961 |
| Agent | Christian Christian Christian, EMV Testhaus GmbH, christian.kiermeier@emv-testhaus.de  , +49942156868 |
| Test Firm | Christian Kiermeier, Element Material Technology Straubing GmbH, christian.kiermeier@element.com  , 49-9421-56868-0 |
| TCB Email | Brandhorst.dirk@phoenix-testlab.de  |
| TCB Scope | A1: Low Power Transmitters below 1 GHz (except Spread Spectrum), Unintentional Radiators, EAS (Part 11) & Consumer ISM devices |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| 1ivGg6ZhN9ta1+nPEAPLAA== | 2017-03-17 | Original Equipment |
Grants
TCB Grant - Application 1ivGg6ZhN9ta1+nPEAPLAA==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
PHOENIX TESTLAB GmbH Koenigswinkel 10 32825 Blomberg, Germany |
Date of Grant: 03/17/2017 Application Dated: 03/17/2017 |
| Elatec GmbH |
| Zeppelinstr. 1 |
| Puchheim, 82178 Germany |
| Attention: Birgit Bachl |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | WP5TWN4F3 |
| Name of Grantee: | Elatec GmbH |
| Equipment Class: | Part 15 Low Power Communication Device Transmitter |
| Notes: | RFID Reader |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 0.125 - 0.125 | ||||
| 15C | 0.134 - 0.134 | ||||
| 15C | 13.56 - 13.56 | 0.01 % |
EAS Grant - Application 1ivGg6ZhN9ta1+nPEAPLAA==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Elatec GmbH Zeppelinstr. 1 Puchheim, 82178 Germany |
Date of Grant: 03/17/2017 Application Dated: 03/17/2017 |
| Attention: Birgit Bachl |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | WP5TWN4F3 |
| Name of Grantee: | Elatec GmbH |
| Equipment Class: | Part 15 Low Power Communication Device Transmitter |
| Notes: | RFID Reader |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 0.125 - 0.125 | ||||
| 15C | 0.134 - 0.134 | ||||
| 15C | 13.56 - 13.56 | 0.01 % |
