TWN4F30 RFID Reader / Writer Test Report - FCC ID WP5TWN4F30
FCC ID WP5TWN4F30
Test report
RFID Reader / Writer
by Elatec GmbH
Document preview loads when visible.
Document Details
| FCC ID | WP5TWN4F30 |
|---|---|
| Document ID | 7912037 |
| Document Type | Test Report |
| Description | Test report |
| Document Title | PB_15.247_RSS-247_BLE |
| Applicant | Elatec GmbH |
| Equipment Class | RFID Reader / Writer |
| Product Code | TWN4F30 |
| Application ID | oBx3fv3qJZjf6I73rL0vJw== |
| Application Purpose | Original Equipment |
| Application Date | 2024-12-18 |
| Frequency Range | 2402-2480 MHz |
| FRN | 0018113688 |
| Test Firm | Element Materials Technology Straubing GmbH |
| Certified By | Katja Frankl GMA Specialist |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Submitted | 2024-12-18 |
| Available | 2024-12-18 |
| Created | 2024-11-27 |
| Modified | 2024-11-27 |
| Pages | 76 |
| File Type | Adobe Acrobat PDF |
| File Size | 2601558 |
| File SHA-256 | 41761115267eb312da4e1e0f4bec49f757586356294c2bcb732c8df97f61a237 |
| PDF Metadata Author | Konrad Graßl |
| PDF Metadata Producer | Microsoft® Word für Microsoft 365 Konrad Graßl |
| FCC.gov Sources | FCC.gov 7912037 |
