TWN4F34 RFID Reader / Writer External Photos - FCC ID WP5TWN4F34
FCC ID WP5TWN4F34
External Photos
RFID Reader / Writer
by Elatec GmbH
Document preview loads when visible.
Document Details
| FCC ID | WP5TWN4F34 |
|---|---|
| Document ID | 8993323 |
| Document Type | External Photos |
| Description | External Photos |
| Document Title | Annex B_EUT pictures external |
| Applicant | Elatec GmbH |
| Equipment Class | RFID Reader / Writer |
| Product Code | TWN4F34 |
| Application ID | YPoWQz7O+ZvzOOX9IRYcsQ== |
| Application Purpose | Original Equipment |
| Application Date | 2026-01-15 |
| Frequency Range | 2402-2480 MHz |
| FRN | 0018113688 |
| Test Firm | Element Materials Technology Straubing GmbH |
| Certified By | Brigit Bachl Compliance Manager |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Submitted | 2026-01-15 |
| Available | 2026-01-15 |
| Created | 2025-12-04 |
| Modified | 2025-12-04 |
| Pages | 3 |
| File Type | Adobe Acrobat PDF |
| File Size | 550301 |
| File SHA-256 | 3310d1d5b40d2ff1dbff352f9224c6fd9b047cb9d4d539a0a621be714dda973c |
| PDF Metadata Author | Patricio Montenegro |
| PDF Metadata Producer | Microsoft® Word for Microsoft 365 Patricio Montenegro |
| FCC.gov Sources | FCC.gov 8993323, FCC.gov 8988904 |
