WB207200 Bluetooth Module Teardown... - FCC ID WS2-WB2072-00
FCC ID WS2-WB2072-00
Internal Photos
Bluetooth Module
Document preview loads when visible.
Document Details
| FCC ID | WS2-WB2072-00 |
|---|---|
| Document ID | 5220158 |
| Document Type | Internal Photos |
| Description | Internal Photos |
| Applicant | Jorjin Technologies Inc. |
| Equipment Class | Bluetooth Module |
| Product Code | WB207200 |
| Application ID | FnQDXxnOTsV2821pApmL8g== |
| Application Purpose | Original Equipment |
| Application Date | 2021-05-03 |
| Frequency Range | 2402-2480 MHz |
| FRN | 0018187252 |
| Test Firm | Compliance Certification Services Inc. Wugu Lab. |
| Certified By | Kevin Tsai Deputy Manager |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Short-Term Confidentiality Date | 10/24/2021 |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2021-04-26 |
| Available | 2021-10-24 |
| Created | 2021-04-14 |
| Modified | 2021-04-23 |
| Pages | 2 |
| File Type | Adobe Acrobat PDF |
| File Size | 1018831 |
| File SHA-256 | 3f383abac8cc3c9ef442b9a083fa50f93501eed5a098c191819bc998c28cabb8 |
| PDF Metadata Author | Wu, Mita (New Taipei City) |
| PDF Metadata Producer | Wu, Mita (New Taipei City) Adobe PDF Library 17.11.238 |
| FCC.gov Sources | FCC.gov 5220158 |
