PTRNKTMBS760 MBS Unit -K Test Setup Photos - FCC ID WT7PTRNKTMBS760

FCC ID WT7PTRNKTMBS760

Test Photos

MBS Unit -K

by Teltronic S.A.U.

Document preview loads when visible.

Document Details

FCC IDWT7PTRNKTMBS760
Document ID2502825
Document TypeTest Setup Photos
DescriptionTest Photos
Document Title44136RRF001_Photographs
ApplicantTeltronic S.A.U.
Equipment ClassMBS Unit -K
Product CodePTRNKTMBS760
Application IDjnS7OYd17kBXHf1tud5eGg==
Application PurposeOriginal Equipment
Application Date2015-01-16
Frequency Range769-775 MHz
FRN0017876152
Test FirmDEKRA Testing and Certification, S.A.U.
Certified ByJose Roman Head of R&D; Certifications and Services
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date07/15/2015
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2015-01-16
Available2015-07-15
Created2014-12-17
Modified2014-12-17
Pages8
File TypeAdobe Acrobat PDF
File Size1183248
File SHA-256aae7744f4e17d0c0f72e02e6d949298e9dfc834fe4822269adb658dea364891a
PDF Metadata AuthorALL
PDF Metadata ProducerGPL Ghostscript 9.04 ALL
FCC.gov SourcesFCC.gov 2502825
