FCC ID WUIYX-BM0X
Bluetooth module
by Winplus Co., Ltd.
Grantee Code: WUI Product Code: YXBM0X
Latest application date: 2015-09-23
Device Images
FCC ID Device Details
| FCC ID | WUIYX-BM0X |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | WUI |
| Product Code | YXBM0X |
| Applicant Business | Winplus Co., Ltd. |
| Related Domains |  winplus.net |
| Equipment Class | Bluetooth module |
| Test Firm | Waltek Services(Shenzhen) Co., Ltd. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2402-2480 MHz | Original Equipment | 2015-09-23 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2015-09-23 | PDF 222.1 KB |
| Internal Photos | Internal Photos | 2015-09-23 | PDF 175.9 KB |
| External Photos | External Photos | 2015-09-23 | PDF 1.9 MB |
| Label | ID Label/Location Info | 2015-09-23 | PDF 89.1 KB |
| Label Location | ID Label/Location Info | 2015-09-23 | PDF 89.1 KB |
| Test Setup Photos | Test Setup Photos | 2015-09-23 | PDF 1.1 MB |
| Test Report | Test Report | 2015-09-23 | PDF 720.5 KB |
| Confidentiality Request Letter | Cover Letter(s) | 2015-09-23 | PDF 175.1 KB |
| Cover Letter | Cover Letter(s) | 2015-09-23 | PDF 114.8 KB |
| Declaration Letter | Cover Letter(s) | 2015-09-23 | PDF 35.1 KB |
| Moduel Approval Letter | Cover Letter(s) | 2015-09-23 | PDF 41.2 KB |
| POA | Cover Letter(s) | 2015-09-23 | PDF 155 KB |
| Block Diagram Metadata only | Block Diagram | PDF 25.7 KB | |
| Schematics Metadata only | Schematics | PDF 20.3 KB | |
| Operational Description Metadata only | Operational Description | PDF 6.3 KB |
Application Information
| Application ID | yASa8cxPUm5hmgj5oZCD2w== |
|---|---|
| Final Action Date | 2015-09-23 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0018215988 |
| Model | YX-BM0X |
| Frequency Range | 2402-2480 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | Bluetooth module |
| Responsible Party | Benson H Leung, Director, bensonleung@winplus.net , 852 2798 8932 |
| Test Firm | philo zhong, Waltek Services(Shenzhen) Co., Ltd., philo@waltek.com.cn  , 8675527553488 |
| TCB Email | TEI@TIMCOENGR.COM  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Limited Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Limited Single Modular Approval. Power listed is conducted. This module is approved for use when installed in host manufacture Winplus Company Ltd., models LM55369. Separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093 and different antenna configurations. The antenna(s) used for this transmitter must not transmit simultaneously with any other antenna or transmitter, except in accordance with FCC multi-transmitter product procedures. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| yASa8cxPUm5hmgj5oZCD2w== | 2015-09-23 | Original Equipment |
Equipment Authorization
| Frequency | Output | Rules |
|---|---|---|
| 2402-2480 MHz | 0.0020000 | 15C |
Grants
TCB Grant - Application yASa8cxPUm5hmgj5oZCD2w==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Timco Engineering, Inc. 849 NW State Road 45 Newberry, FL 32669 |
Date of Grant: 09/23/2015 Application Dated: 09/23/2015 |
| Winplus Co., Ltd. |
| Suites 6-11, 7th Floor, Corporation Park, 11 On La |
| Shatin, Hong Kong |
| Attention: Benson Leung , Director |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | WUIYX-BM0X |
| Name of Grantee: | Winplus Co., Ltd. |
| Equipment Class: | Digital Transmission System |
| Notes: | Bluetooth module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 | 0.002 |
| Limited Single Modular Approval. Power listed is conducted. This module is approved for use when installed in host manufacture Winplus Company Ltd., models LM55369. Separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093 and different antenna configurations. The antenna(s) used for this transmitter must not transmit simultaneously with any other antenna or transmitter, except in accordance with FCC multi-transmitter product procedures. |
EAS Grant - Application yASa8cxPUm5hmgj5oZCD2w==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Winplus Co., Ltd. Suites 6-11, 7th Floor, Corporation Park, 11 On La P.O. Box , Shatin, Hong Kong |
Date of Grant: 09/23/2015 Application Dated: 09/23/2015 |
| Attention: Benson Leung , Director |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | WUIYX-BM0X |
| Name of Grantee: | Winplus Co., Ltd. |
| Equipment Class: | Digital Transmission System |
| Notes: | Bluetooth module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 | 0.002 |
| Limited Single Modular Approval. Power listed is conducted. This module is approved for use when installed in host manufacture Winplus Company Ltd., models LM55369. Separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093 and different antenna configurations. The antenna(s) used for this transmitter must not transmit simultaneously with any other antenna or transmitter, except in accordance with FCC multi-transmitter product procedures. |
