A200X GSM mobile phone Test Setup Photos - FCC ID WVBA200X
FCC ID WVBA200X
Test setup
GSM mobile phone
Document preview loads when visible.
Document Details
| FCC ID | WVBA200X |
|---|---|
| Document ID | 3140384 |
| Document Type | Test Setup Photos |
| Description | Test setup |
| Document Title | FCC RF Test Report |
| Applicant | Brightstar Corporation |
| Equipment Class | GSM mobile phone |
| Product Code | A200X |
| Application ID | DWx7zv7Cor6djL9kCeCPIw== |
| Application Purpose | Original Equipment |
| Application Date | 2016-09-21 |
| Frequency Range | 2402-2480 MHz |
| FRN | 0018873513 |
| Test Firm | SPORTON International(ShenZhen) Inc. |
| Certified By | Michael Lin Vice President |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Short-Term Confidentiality Date | 03/19/2017 |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Submitted | 2016-09-20 |
| Available | 2017-03-19 |
| Created | 2017-12-14 |
| Modified | 2017-12-14 |
| Pages | 2 |
| File Type | Adobe Acrobat PDF |
| File Size | 44962 |
| File SHA-256 | a90a4eaf5d628f5166e786ccfe0354f6b76d5aefd35e8c4f8bfd9b691cf498e5 |
| PDF Metadata Author | WBU Documentation Depr. |
| PDF Metadata Producer | GPL Ghostscript 9.18 WBU Documentation Depr. |
| FCC.gov Sources | FCC.gov 3140384 |
