QY8500 CAR NAVIGATION Teardown Internal Photos - FCC ID WY2QY8500

FCC ID WY2QY8500

Internal Photos.pdf

CAR NAVIGATION

by Faurecia Clarion Electronics (Xiamen) Co., Ltd.

Document preview loads when visible.

Document Details

FCC IDWY2QY8500
Document ID2812019
Document TypeInternal Photos
DescriptionInternal Photos.pdf
Document Titleinternal Photos
ApplicantFaurecia Clarion Electronics (Xiamen) Co., Ltd.
Equipment ClassCAR NAVIGATION
Product CodeQY8500
Application ID+1sEO3SgiqJlWvszv7kmmQ==
Application PurposeOriginal Equipment
Application Date2015-11-16
Frequency Range2402-2480 MHz
FRN0024082281
Test FirmBureau Veritas Shenzhen Co., Ltd. Dongguan Branch
Certified BySam Tung EMC Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2015-11-13
Available2015-11-16
Created2015-10-26
Modified2015-10-26
Pages11
File TypeAdobe Acrobat PDF
File Size1664374
File SHA-2565aa7e8460c2e09d3d7cd1f33a0d39201ee940ab31c2336f494f2b4e9e3cfc8f4
PDF Metadata Authorcbchen
PDF Metadata ProducerGPL Ghostscript 9.07 PDFCreator Version 1.7.1
FCC.gov SourcesFCC.gov 2812019
