FCC ID WY7-SWAN2
Wireless Module
by SHIMANO INC.
Grantee Code: WY7 Product Code: SWAN2
Latest application date: 2015-12-18
Device Images
FCC ID Device Details
| FCC ID | WY7-SWAN2 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | WY7 |
| Product Code | SWAN2 |
| Applicant Business | SHIMANO INC. 🇯🇵 |
| Related Domains |  sic.shimano.co.jp  jty.yuden.co.jp |
| Equipment Class | Wireless Module |
| Test Firm | Bureau Veritas CPS(H.K.) Ltd., Taoyuan Branch |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2402-2480 MHz | Change in identification of presently authorized equipment. Original FCC ID: RYYEYAGJN Grant Date: 08/11/2015 | 2015-12-18 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Users Manual | Users Manual | 2016-04-15 | PDF 362.1 KB |
| External Photos | External Photos | 2016-04-15 | PDF 333.2 KB |
| ID Label/Location Info | ID Label/Location Info | 2015-12-18 | PDF 103.4 KB |
| Comparison List | Cover Letter(s) | 2015-12-18 | PDF 20.2 KB |
| Declaration of authorization | Cover Letter(s) | 2015-12-18 | PDF 216.3 KB |
| Declaration of authorization use of TCF | Cover Letter(s) | 2015-12-18 | PDF 19.4 KB |
| declaration for OEM product | Cover Letter(s) | 2015-12-18 | PDF 276.3 KB |
| declaration of power adjustment | Cover Letter(s) | 2015-12-18 | PDF 17.3 KB |
Application Information
| Application ID | 5vircSRNvpkz4xKH/AwtQQ== |
|---|---|
| Final Action Date | 2015-12-18 |
| Application Purpose | Change in identification of presently authorized equipment. Original FCC ID: RYYEYAGJN Grant Date: 08/11/2015 |
| Applicant FRN | 0018351890 |
| Model | SWAN2 |
| Frequency Range | 2402-2480 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | Wireless Module |
| Responsible Party | Toshihiko Takahashi, Manager, tkhsts@sic.shimano.co.jp , +81-72-223-7019 |
| Agent | Hiroyuki Hiroyuki Hiroyuki, TAIYO YUDEN CO., LTD., ty-approval@jty.yuden.co.jp , 81-27-324-2313 |
| Technical Contact | Hiroyuki Masuda, TAIYO YUDEN CO., LTD., ty-approval@jty.yuden.co.jp , 81-27-324-2313 |
| Non-Technical Contact | Kiyoko Kariya, TAIYO YUDEN CO., LTD., ty-approval@jty.yuden.co.jp , 81-27-324-2313 |
| Test Firm | Richard Chen, Bureau Veritas CPS(H.K.) Ltd., Taoyuan Branch, richard.chen@bureauveritas.com  , +886-(0)3-260-0884 |
| TCB Email | certification@telefication.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | Yes |
| Short-Term Confidentiality Date | 04/15/2016 |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Limited Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Limited Modular Approval: Power output listed is conducted. This grant is valid only when the module is sold to OEM integrators and must be installed by the OEM or OEM integrators. The antennas used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. End-users may not be provided with the module installation instructions. OEM integrators and end-users must be provided with transmitter operating conditions for satisfying RF exposure compliance. The output power is adjustable in 8 steps down to -34dB referenced to the value listed. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| 5vircSRNvpkz4xKH/AwtQQ== | 2015-12-18 | Change in identification of presently authorized equipment. Original FCC ID: RYYEYAGJN Grant Date: 08/11/2015 |
Grants
TCB Grant - Application 5vircSRNvpkz4xKH/AwtQQ==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Telefication B.V. Wilmersdorf 50 Apeldoorn, NL-7300 AC Netherlands |
Date of Grant: 12/18/2015 Application Dated: 12/16/2015 |
| SHIMANO INC. |
| 3-77 Oimatsu-cho Sakai-ku |
| Sakai City, Osaka, 590-8577 Japan |
| Attention: Toshihiko Takahashi , Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | WY7-SWAN2 |
| Name of Grantee: | SHIMANO INC. |
| Equipment Class: | Digital Transmission System |
| Notes: | Wireless Module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 | 0.0034 | |||
| 15C | 2403.0 - 2480.0 | 0.0037 |
| Limited Modular Approval: Power output listed is conducted. This grant is valid only when the module is sold to OEM integrators and must be installed by the OEM or OEM integrators. The antennas used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. End-users may not be provided with the module installation instructions. OEM integrators and end-users must be provided with transmitter operating conditions for satisfying RF exposure compliance. The output power is adjustable in 8 steps down to -34dB referenced to the value listed. |
EAS Grant - Application 5vircSRNvpkz4xKH/AwtQQ==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
SHIMANO INC. 3-77 Oimatsu-cho Sakai-ku Sakai City, Osaka, 590-8577 Japan |
Date of Grant: 12/18/2015 Application Dated: 12/16/2015 |
| Attention: Toshihiko Takahashi , Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | WY7-SWAN2 |
| Name of Grantee: | SHIMANO INC. |
| Equipment Class: | Digital Transmission System |
| Notes: | Wireless Module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 | 0.0034 | |||
| 15C | 2403.0 - 2480.0 | 0.0037 |
| Limited Modular Approval: Power output listed is conducted. This grant is valid only when the module is sold to OEM integrators and must be installed by the OEM or OEM integrators. The antennas used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. End-users may not be provided with the module installation instructions. OEM integrators and end-users must be provided with transmitter operating conditions for satisfying RF exposure compliance. The output power is adjustable in 8 steps down to -34dB referenced to the value listed. |
| Mail To: |
