BTS70 BLUETOOTH RECEIVER Block Diagram - FCC ID WY9-BTS-70

FCC ID WY9-BTS-70

Block Diagram

BLUETOOTH RECEIVER

by Telnova Technology Co., Ltd.

Document preview loads when visible.

Document Details

FCC IDWY9-BTS-70
Document ID1982228
Document TypeBlock Diagram
DescriptionBlock Diagram
Document Titleblockdiagram and description
ApplicantTelnova Technology Co., Ltd.
Equipment ClassBLUETOOTH RECEIVER
Product CodeBTS70
Application ID5VA9oUDBltkxODQuXxrYVg==
Application PurposeOriginal Equipment
Application Date2013-06-04
Frequency Range2402-2480 MHz
FRN0018352021
Test FirmWaltek Services(Shenzhen) Co., Ltd.
Certified ByPHILO ZHONG GENERAL MANAGER
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2013-06-04
Available2013-06-04
Created2013-06-03
Modified2013-06-03
Pages1
File TypeAdobe Acrobat PDF
File Size28292
File SHA-25644664d9511e7370cd939cb8660ff2b3e76d571bb4b3ab26d3bccc339cc49ed03
PDF Metadata AuthorZero.Zhou
PDF Metadata CreatorPScript5.dll Version 5.2
PDF Metadata ProducerAcrobat Distiller 7.0 (Windows)
FCC.gov SourcesFCC.gov 1982228
