RC2 RADIO REMOTE CONTROL Block Diagram - FCC ID X55-RC2

FCC ID X55-RC2

Block Diagram

RADIO REMOTE CONTROL

by Astera LED-Technology GmbH

Document preview loads when visible.

Document Details

FCC IDX55-RC2
Document ID1263114
Document TypeBlock Diagram
DescriptionBlock Diagram
Document TitleDrawing2 Model (1)
ApplicantAstera LED-Technology GmbH
Equipment ClassRADIO REMOTE CONTROL
Product CodeRC2
Application IDGpSQllI9vivc8EcLyhM7KA==
Application PurposeOriginal Equipment
Application Date2010-04-08
Frequency Range920 MHz
FRN0019416791
Test FirmBontek Compliance Testing Laboratory Ltd
Certified ByNorbert Ernst General Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2010-04-08
Available2010-04-08
Created2009-12-21
Modified2010-02-10
Pages1
File TypeAdobe Acrobat PDF
File Size242994
File SHA-256609be48cef7cc3f3b4634cc00381c014e1caf145e6f10285a29a873f8a5c81ce
PDF Metadata Authorjoel
PDF Metadata CreatorPScript5.dll Version 5.2.2
PDF Metadata ProducerGPL Ghostscript 8.61
FCC.gov SourcesFCC.gov 1263114
