PL7602 Wii Remote Block Diagram - FCC ID X5B-PL7602

FCC ID X5B-PL7602

Block Diagram

Wii Remote

by Performance Designed Products, LLC

Document preview loads when visible.

Document Details

FCC IDX5B-PL7602
Document ID1254252
Document TypeBlock Diagram
DescriptionBlock Diagram
Document Titleblock
ApplicantPerformance Designed Products, LLC
Equipment ClassWii Remote
Product CodePL7602
Application IDd4OLWWerAT4DQg8M6HBn5A==
Application PurposeOriginal Equipment
Application Date2010-03-19
Frequency Range2402-2480 MHz
FRN0019508654
Test FirmIntertek Testing Services Shenzhen Ltd.
Certified ByShawn Xing Assistant Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2010-03-19
Available2010-03-19
Created2010-03-15
Modified2010-03-15
Pages2
File TypeAdobe Acrobat PDF
File Size114118
File SHA-25683e7c65bf9c62b467d04732ec44f5e2750a3e4a6f2fc4706c4bbe7b98d1ed20a
PDF Metadata AuthorBiLi
PDF Metadata CreatorPDFCreator Version 0.9.3
PDF Metadata ProducerAcrobat Distiller 8.0.0 (Windows)
FCC.gov SourcesFCC.gov 1254252
