X8NOM2000 Amateur Radio Service Linear HF... - FCC ID X8NX8NOM2000
FCC ID X8NX8NOM2000
Measurements conformance Part 97.
Amateur Radio Service Linear HF Amplifier
Document preview loads when visible.
Document Details
| FCC ID | X8NX8NOM2000 |
|---|---|
| Document ID | 2297738 |
| Document Type | Attestation Statements |
| Description | Measurements conformance Part 97. |
| Applicant | Array Solutions dba Array Solutions |
| Equipment Class | Amateur Radio Service Linear HF Amplifier |
| Product Code | X8NOM2000 |
| Application ID | kNbQZEQSwjtXQqXVKHhXXQ== |
| Application Purpose | Original Equipment |
| Application Date | 2014-09-09 |
| Frequency Range | 1.8-54 MHz |
| FRN | 0003042447 |
| Certified By | John D Terleski President - Array Solutions |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2014-06-17 |
| Available | 2014-09-09 |
| Created | 2014-06-17 |
| Modified | 2014-06-17 |
| Pages | 3 |
| File Type | Adobe Acrobat PDF |
| File Size | 264816 |
| File SHA-256 | cc6bb30278ea20238bd8878f7e49ab2cb24901526dd95f71db1cc17bd0132bc4 |
| PDF Metadata Author | Krassy Petkov |
| PDF Metadata Producer | Microsoft® Office Word 2007 Microsoft® Office Word 2007 |
| FCC.gov Sources | FCC.gov 2297738 |
