703 Swiftpoint USB-A Receiver Test Setup Photos - FCC ID X8Y-703

FCC ID X8Y-703

Test photos

Swiftpoint USB-A Receiver

by Swiftpoint Limited

Document preview loads when visible.

Document Details

FCC IDX8Y-703
Document ID9480987
Document TypeTest Setup Photos
DescriptionTest photos
ApplicantSwiftpoint Limited
Equipment ClassSwiftpoint USB-A Receiver
Product Code703
Application IDaCAHrv8sHSochpu3tZ4kKw==
Application PurposeOriginal Equipment
Application Date2026-07-20
Frequency Range2402-2480 MHz
FRN0019661875
Test FirmSHENZHEN CTA TESTING TECHNOLOGY CO., LTD.
Certified ByERIC WANG
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Modular EquipmentDoes not apply
Composite DeviceNo
Submitted2026-07-20
Available2026-07-20
Created2026-07-16
Modified2026-07-16
Pages3
File TypeAdobe Acrobat PDF
File Size725542
File SHA-256a1ea1376c2d6a4ece4596339e9fce421c1d68133c02433bc1fa9bad5939f2bb6
PDF Metadata AuthorDESKTOP-OBPLJ1L
PDF Metadata ProducerMicrosoft® Word 2016 Microsoft® Word 2016
FCC.gov SourcesFCC.gov 9480987
